Dmisteinbergite

Ca(Al2Si2O8)
IMA status
  • Approved
IMA symbol
Dsb
Discovered
1989
IMA approved
1989
Also known as
  • Dmisteinbergiet
  • IMA1989-010

Where it forms, where it's found

Geological setting

fissures in burning coal mine dumps

altered gabbro

Type locality
Coal mine No. 45
  1. Kopeysk
  2. Chelyabinsk Oblast
  3. Russia
7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Streak
white
Cleavage
Perfect
Density
2.73 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.575 – 1.58
Surface relief
Moderate
Principal indices
nω 1.575 · nε 1.58
Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#88
Cell parameters
a = 5.1123(2) Å · c = 14.7420(7) Å
Z
2
Type-locality form

hexagonal platy crystals

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
46.01%
14SiSiliconSilicon228.08556.170
20.19%
13AlAluminiumAluminium226.98253.964
19.40%
20CaCalciumCalcium140.07840.078
14.40%
Total278.204100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • Na
  • K

Synonyms

  • Dmisteinbergiet
  • IMA1989-010

In other languages

French
dmisteinbergite
German
Dmisteinbergit · IMA 1989-010
Italian
Dmisteinbergite
Portuguese
dmisteinbergita · Dmisteinbergite
Chinese
德米斯滕贝尔格石

Classification

Strunz
10th ed.

9.EG.15

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EGDouble nets with 6-membered and larger ringsGroup
  • 9.EG.15DmisteinbergiteSpecies
Dana
8th ed.

76.01.07.01

  • 76Tectosilicates Al-si FrameworkClass
  • 76.01Al-Si Framework with Al-Si frameworksType
  • 76.01.07— unnamed intermediate level —Group
  • 76.01.07.01DmisteinbergiteSpecies
CIM

16.9.5

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.9Aluminosilicates of CaGroup
  • 16.9.5DmisteinbergiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1952Donnay, G. H. (1952) Hexagonal CaAl2Si2O8. Acta Crystallographica, 5 (1) 153 doi:10.1107/s0365110x52000423DOI: 10.1107/s0365110x52000423
  2. 1952Davis, G.L., Tuttle, O.F. (1952) Two new crystalline phases of the anorthite composition, CaO·Al2O3·2SiO2. American Journal of Science, Bowen Volume Publication No. 1200: 107-114.
  3. 1959Takeuchi, Y., Donnay, G. (1959) The crystal structure of hexagonal CaAl2Si2O8. Acta Crystallographica, 12 (6) 465-470 doi:10.1107/s0365110x59001396DOI: 10.1107/s0365110x59001396
  4. 1990Chesnokov, B.V., Lotova, E.V., Nigmatullina, E.N., Pavlutchenko, V S., Bushmakin, A.F. (1990) Dmishteinbergit, CaAl2Si2O8, (hexagonal), a new mineral. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 119(5): 43-46.
  5. 1991Abe, Toshiya, sukamoto, Katsuo, Sunagawa, Ichiro (1991) Nucleation, growth and stability of CaAl2Si2O8 polymorphs. Physics and Chemistry of Minerals, 17 (6) doi:10.1007/bf00202227DOI: 10.1007/bf00202227
