Svyatoslavite

Ca(Al2Si2O8)
IMA status
  • Approved
IMA symbol
Svy
Discovered
1988
IMA approved
1988
Also known as
  • IMA1988-012
  • Svyatoslaviet

Where it forms, where it's found

Geological setting

Burning coal dumps, at temperatures not below 700-900°C, as a sublimate on fracture walls in coal.

Type locality
Coal mine No. 45
  1. Kopeysk
  2. Chelyabinsk Oblast
  3. Russia

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Streak
white
Tenacity
brittle
Cleavage
Poor/Indistinct

Poor on (100)

Fracture
Conchoidal
Density
2.695 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 37° · 2V calc = 36°
Refractive index
1.552 – 1.581
Surface relief
Moderate
Principal indices
nα 1.552 · nβ 1.578 · nγ 1.581
Dispersion
weak to distinct
UV response
Fluoresces weakly yellowish in 360 nm UV.
Notes

Z = a, Y = b, X = c

Michel-Lévy diagramhighlighted lineδ = 0.0290
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]290 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation290 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#9
Cell parameters
a = 8.232(5) Å · b = 8.606(10) Å · c = 4.852(5) Å
Ratio a:b:c
1 : 1.045 : 0.589
Z
2
Morphology

Type material: Elongate [100] with the main forms being (011) and (100). (110) is common, but weakly developed.

Type-locality form

Colorless prismatic crystals up to 0.5 to 0.8 mm.

Comment

Pseudo-orthorhombic. Space group P1211. Formerly assumed to be P21212.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
46.01%
14SiSiliconSilicon228.08556.170
20.19%
13AlAluminiumAluminium226.98253.964
19.40%
20CaCalciumCalcium140.07840.078
14.40%
Total278.204100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mg
  • Na
  • K

Synonyms

  • IMA1988-012
  • Svyatoslaviet

In other languages

German
IMA 1988-012 · Svyatoslavit
Italian
Svyatoslavite

Classification

Strunz
10th ed.

9.FA.45

  • 9SilicatesClass
  • 9.FTektosilicates without zeolitic H2ODivision
  • 9.FATektosilicates without additional non-tetrahedral anionsGroup
  • 9.FA.45SvyatoslaviteSpecies
Dana
8th ed.

76.01.06.04

  • 76Tectosilicates Al-si FrameworkClass
  • 76.01Al-Si Framework with Al-Si frameworksType
  • 76.01.06Banalsite groupGroup
  • 76.01.06.04SvyatoslaviteSpecies
CIM

16.9.4

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.9Aluminosilicates of CaGroup
  • 16.9.4SvyatoslaviteSpecies

Group, growth & confusion

Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1952Davis, G.L., Tuttle, O.F. (1952) Two new crystalline phases of the anorthite composition, CaO·Al2O3·2SiO2. American Journal of Science, Bowen Volume Publication No. 1200: 107-114.
  2. 1973Takéuchi, Y., Haga, N., Ito, J. (1973) The crystal structure of monoclinic CaAl2Si2O8: a case of monoclinic structure closely simulating orthorhombic symmetry. Zeitschrift für Kristallographie, 137 (5-6). 380-398 doi:10.1524/zkri.1973.137.5-6.380 DOI: 10.1524/zkri.1973.137.5-6.380
  3. 1989Chesnokov, B.V., Lotova, E.V., Pavlyuchenko, V.S., Usova, L.V., Bushmakin, A.F., Nishanbayev, T.P. (1989) Svyatoslavite CaAl2Si2O8 (orthorhombic) — a new mineral. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 118(2): 111-114.
  4. 1991Jambor, John L., Grew, Edward S. (1991) New Mineral Names. American Mineralogist, 76 (1-2) 299-305
  5. 2007(2007) Svyatoslavite. Handbook of Mineralogy. Mineralogical Society of America
