Dorrite

Ca4[Mg3Fe3+9]O4[Si3Al8Fe3+O36]
IMA status
  • Approved
IMA symbol
Dor
Discovered
1987
IMA approved
1987
Also known as
  • Dorriet
  • IMA1987-054

Where it forms, where it's found

Type locality
Durham Ranch paralava occurrence
  1. Reno Junction
  2. Campbell County
  3. Wyoming
  4. USA
15recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Sub-metallic
Transparency
Opaque
Colour
red-brown · brown-black · dark brown
Streak
brownish grey
Tenacity
brittle
Cleavage
Distinct/Good

Good on (010) and (001).

Fracture
Irregular/Uneven
Density
3.059 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 90° · 2V calc = 88°
Refractive index
1.82 – 1.86
Surface relief
Very high
Principal indices
nα 1.82 · nβ 1.84 · nγ 1.86
Pleochroism
Strong

X = red-orange brown; Y = yellowish brown; Z = greenish brown.

Dispersion
small
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 10.5 Å · b = 10.89 Å · c = 9.91 Å
Cell angles
α = 106.26 ° · β = 95.16 ° · γ = 124.75 °
Ratio a:b:c
1 : 1.037 : 0.944
Morphology

As anhedral to prismatic grains, to 0.1 mm; some grains exhibit hopper and skeletal habits

Twinning

Twinned by two-fold rotation about the pseudomonoclinic [010] axis.

Comment

Point Group: 1 or _1 . ; Space Group: P1 or P_1 .

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4015.999639.960
36.95%
26FeIronIron1055.845558.450
32.25%
13AlAluminiumAluminium826.982215.856
12.46%
20CaCalciumCalcium440.078160.312
9.26%
14SiSiliconSilicon328.08584.255
4.87%
12MgMagnesiumMagnesium324.30572.915
4.21%
Total1731.748100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Cr
  • Mn
  • Na
  • K

Synonyms

  • Dorriet
  • IMA1987-054

In other languages

French
Dorrite
German
Dorrit · IMA 1987-054
Italian
Dorrite
Portuguese
Dorrita · IMA1987-054
Chinese
杜尔石

Classification

Strunz
10th ed.

9.DH.40

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DHInosilicates with 4-periodic single chains, Si4O12Group
  • 9.DH.40DorriteSpecies
Dana
8th ed.

69.02.1a.02

  • 69Inosilicates Chains with Side Branches or LoopsClass
  • 69.02Chains with Side Branches or Loops with P>2Type
  • 69.02.1a— unnamed intermediate level —Group
  • 69.02.1a.02DorriteSpecies
CIM

16.23.2

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.23Aluminosilicates of Fe, Ca, and MgGroup
  • 16.23.2DorriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1988Cosca, Michael A., Rouse, Roland C., Essene, Eric J. (1988) Dorrite [Ca2(Mg2Fe3+4)(Al4Si2)O20], a new member of the aenigmatite group from a pyrometamorphic melt-rock. American Mineralogist, 73 (11-12) 1440-1448
  2. 1994Burt, D.M. (1994) Vector representation of some mineral compositions in the aenigmatite group, with special reference to hogtuvaite. The Canadian Mineralogist: 32: 449-457.
  3. 1996Jensen, B. B. (1996) Solid solution among members of the aenigmatite group. Mineralogical Magazine, 60 (403) 982-986 doi:10.1180/minmag.1996.060.403.14 DOI: 10.1180/minmag.1996.060.403.14
  4. 1999Kunzmann, Thomas (1999) The aenigmatite-rhönite mineral group. European Journal of Mineralogy, 11 (4) 743-756 doi:10.1127/ejm/11/4/0743DOI: 10.1127/ejm/11/4/0743
  5. 2008Grew, E. S., Hålenius, U., Pasero, M., Barbier, J. (2008) Recommended nomenclature for the sapphirine and surinamite groups (sapphirine supergroup) Mineralogical Magazine, 72 (4) 839-876 doi:10.1180/minmag.2008.072.4.839 DOI: 10.1180/minmag.2008.072.4.839
