Dumortierite

AlAl6BSi3O18
IMA status
  • Approved
  • Grandfathered
IMA symbol
Dum
Discovered
1879

Where it forms, where it's found

Geological setting

In Al rich regionally metamorphosed rocks disseminated and in veinlets cutting schist, also in pegmatitic veins.

Type locality
Ducarre's Quarry
  1. Beaunant
  2. Chaponost
  3. Lyon
  4. Rhône
  5. Auvergne-Rhône-Alpes
  6. France
199recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107 – 8/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Blue · greenish-blue · violet-blue · pale blue · pink · red
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (100), poor on (110),

Density
3.21 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 20 – 52° · 2V calc = 30°
Refractive index
1.659 – 1.692
Surface relief
High
Principal indices
nα 1.659 – 1.678 · nβ 1.684 – 1.691 · nγ 1.686 – 1.692
Pleochroism
Strong

X = deep blue or violet; Y = yellow to red-violet or nearly colorless; Z = colorless or very pale blue.

Dispersion
r > v or r < v
Extinction
Parallel. X = c; Y = b; Z = a.
UV response
blue shortwave-excited luminescence excited by SW UV caused by titanate groups (TiO<sub>6</sub>)
Michel-Lévy diagramhighlighted lineδ = 0.0205
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]205 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation205 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 11.828(1) Å · b = 20.243(3) Å · c = 4.7001(5) Å
Ratio a:b:c
1 : 1.711 : 0.397
Z
4
Twinning

Common on (110) sometimes producing trillings.

Parting
parting on (001)
Comment

Non-standard space group setting (Pmcn).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
50.35%
13AlAluminiumAluminium726.982188.874
33.03%
14SiSiliconSilicon328.08584.255
14.73%
5BBoronBoron110.81010.810
1.89%
Total571.921100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ti
  • Mg
  • Ca

In other languages

French
Dumortierite
German
Dumortierit
Spanish
Dumortierita
Italian
dumortierite
Portuguese
Dumortierita · dumortierite
Japanese
デュモルチェライト
Chinese
蓝线石
Traditional Chinese
藍線石
Russian
Дюмортьерит

Classification

Strunz
10th ed.

9.AJ.10

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AJNesosilicates with BO3 triangles and/or B[4], Be[4] tetrahedra, cornersharing with SiO4Group
  • 9.AJ.10DumortieriteSpecies
Dana
8th ed.

54.01.02.01

  • 54Nesosilicates Borosilicates and Some BeryllosilicatesClass
  • 54.01Borosilicates and Some Beryllosilicates with (BO3)Type
  • 54.01.02Dumortierite groupGroup
  • 54.01.02.01DumortieriteSpecies
CIM

17.5.25

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.25DumortieriteSpecies

Group, growth & confusion

In the same group
1 members
Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1881Gonnard, Ferdinand (1881) Sur l'existence d'une espèce minérale nouvelle, la Dumortiérite, dans le gneiss de Beaunan, au-dessus des anciens aqueducs gallo-romains de la vallée de l'Izeron (Rhône) Bulletin de Minéralogie, 4 (1) 2-5 doi:10.3406/bulmi.1881.1606DOI: 10.3406/bulmi.1881.1606
  2. 1881Damour, Augustin-Alexis (1881) Analyse de la Dumortiérite. Bulletin de Minéralogie, 4 (1) 6-8 doi:10.3406/bulmi.1881.1607DOI: 10.3406/bulmi.1881.1607
  3. 1902Ford, William Ebenezer (1902) On the chemical composition of dumortierite. American Journal of Science, 4th. Series: 14: 426-430.
  4. 1903Ford, W. E. (1903) Ueber die chemische Zusammensetzung des Dumortierit. Zeitschrift für Kristallographie, 37 (1-6). 417-421 doi:10.1524/zkri.1903.37.1.417DOI: 10.1524/zkri.1903.37.1.417
  5. 1905Schaller, Waldemar T. (1905) Dumortierite. Contributions to mineralogy from the United States Geological Survey, Bulletin 262, US Geological Survey. p.91-120.
