Esperite

PbCa2(ZnSiO4)3
IMA status
  • Approved
IMA symbol
Epr
Discovered
1928
IMA approved
1964
Also known as
  • Calcium-Larsenite
  • IMA1964-027

Where it forms, where it's found

Geological setting

Metamorphosed stratiform zinc-iron-manganese orebody.

Type locality
Parker shaft
  1. Franklin Mine
  2. Franklin
  3. Sussex County
  4. New Jersey
  5. USA

41.1203°, -74.5828°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · off-white · pale tan

My be orange or light brown due to finr-grained inclusions of andradite or zincite

Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (010) and (100), poor on (101)

Fracture
Irregular/Uneven
Density
4.28 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 5 – 40°
Refractive index
1.762 – 1.774
Surface relief
High
Principal indices
nα 1.762 · nβ 1.770 · nγ 1.774
Birefringence
0.012
Pleochroism
Non-pleochroic
Dispersion
very strong
UV response
Bright yellow (SW UV)(Franklin); dull yellow (LW UV)
Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 17.628 Å · b = 8.27 Å · c = 30.52 Å
Cell angles
β = 90 °
Ratio a:b:c
1 : 0.469 : 1.731
Unit cell volume
4449.31 ų
Z
12
Morphology

Coarse granular aggregates, massive, to 9 cm

Twinning

Commonly triply twinned (~60° rotational twinning around the b axis).

Type-locality form

Massive off-white material in massive ore.

Comment

P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
27.27%
30ZnZincZinc365.380196.140
25.82%
8OOxygenOxygen1215.999191.988
25.27%
14SiSiliconSilicon328.08584.255
11.09%
20CaCalciumCalcium240.07880.156
10.55%
Total759.739100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mn
  • Mg

Synonyms

  • Calcium-Larsenite
  • IMA1964-027

In other languages

French
Esperite
German
Esperit · IMA 1964-027
Spanish
Esperita
Italian
Esperite
Chinese
硅钙铅锌矿

Classification

Strunz
10th ed.

9.AB.15

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.ABNesosilicates without additional anions; cations in [4] and greater coordinationGroup
  • 9.AB.15EsperiteSpecies
Dana
8th ed.

51.02.01.03

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.02Insular SiO4 Groups Only with cations in [4] as well as >[4]Type
  • 51.02.01Trimerite groupGroup
  • 51.02.01.03EsperiteSpecies
CIM

14.7.19

  • 14Silicates not Containing AluminumClass
  • 14.7Silicates of Ba, Sr and ZnGroup
  • 14.7.19EsperiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. http://www.mindat.org/mesg-104-366501.html [discussion of fluorescence]
  2. 1928Palache, C., Bauer, L. H., Berman, H. (1928) Larsenite, calcium-larsenite and associated minerals at Franklin, New Jersey. American Mineralogist, 13 (7) 334-340
  3. 1928Palache, C., Bauer, L. H., Berman, H. (1928) Larsenite and calcium-larsenite, new members of the chrysolite group, from Franklin, New Jersey. (Preliminary Notice) American Mineralogist, 13 (4) 142-144
  4. 1935Palache, Charles (1935) The minerals of Franklin and Sterling Hill, Sussex County, New Jersey. Professional Paper 180. US Geological Survey 135 pp. doi:10.3133/pp180 DOI: 10.3133/pp180
  5. 1965Moore, Paul B., Ribbe, Paul H. (1965) A study of "calcium-larsenite" renamed esperite. American Mineralogist, 50 (9) 1170-1178
