Glaucochroite

CaMn2+(SiO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Glc
Discovered
1899
Also known as
  • Calcotephroit
  • Calcotephroita
  • Calcotephroite
  • +3 more

Where it forms, where it's found

Geological setting

Metamorphosed stratiform zinc deposit.

Type locality
Franklin Mine
  1. Franklin
  2. Sussex County
  3. New Jersey
  4. USA

41.1158°, -74.5875°

8recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent · Opaque
Colour
Bluish-gray · pink · brown · or white.

May show the alexandrite-effect

Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

(001)

Fracture
Conchoidal · Sub-Conchoidal
Density
3.407 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 61° · 2V calc = 60°
Refractive index
1.679 – 1.736
Surface relief
High
Principal indices
nα 1.679 – 1.686 · nβ 1.716 – 1.723 · nγ 1.729 – 1.736
Birefringence
0.050
Pleochroism
Non-pleochroic
Dispersion
medium
Extinction
Parallel
UV response
Not fluorescent in UV.
Michel-Lévy diagramhighlighted lineδ = 0.0500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]500 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation500 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 4.923 Å · b = 11.192 Å · c = 6.512 Å
Ratio a:b:c
1 : 2.273 : 1.323
Z
4
Morphology

Usually massive, rarely in short prismatic crystals.

Type-locality form

Massive material in franklinite-willemite-zincite ore with hardystonite and calcite.

Comment

Pbnm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
34.21%
25MnManganeseManganese154.93854.938
29.36%
20CaCalciumCalcium140.07840.078
21.42%
14SiSiliconSilicon128.08528.085
15.01%
Total187.097100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Zn
  • Pb
  • Mg

Synonyms

  • Calcotephroit
  • Calcotephroita
  • Calcotephroite
  • Glauchchroite
  • Glaucochroit
  • Glaucochroita

In other languages

French
Glaucochroïte
German
Glaukochroit
Spanish
Calcotefroíta · Glaucocroíta
Italian
glaucocroite
Chinese
钙锰橄榄石
Arabic
جلوكوكرويت

Classification

Strunz
10th ed.

9.AC.05

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.ACNesosilicates without additional anions; cations in octahedral [6] coordinationGroup
  • 9.AC.05GlaucochroiteSpecies
Dana
8th ed.

51.03.02.03

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.03Insular SiO4 Groups Only with all cations in octahedral [6] coordinationType
  • 51.03.02Monticellite - Kirschsteinite seriesGroup
  • 51.03.02.03GlaucochroiteSpecies
CIM

14.18.14

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.14GlaucochroiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1899Penfield, Samuel Lewis; Hyde, Warren Charles (1899) Some New Minerals from the Zinc Mines at Franklin, N. J., and Note Concerning the Chemical Composition of Ganomalite. American Journal Of Science, S. 3 Vol. 8. 339-353
  2. 1932Greer, W. L. C. (1932) Mix-crystals of Ca2SiO4 and Mn2SiO4. American Mineralogist, 17 (4) 135-142
  3. 1951O'Mara, J. H. (1951) Unit cell and space group of glaucochroite. American Mineralogist, 36 (11-12) 918
  4. 1978Lager, George A., Meagher, E. P. (1978) High-temperature structural study of six olivines. American Mineralogist, 63 (3-4) 365-377
  5. 1987Leavens, Peter B., Dunn, Pete J., Burt, Donald M. (1987) Glaucochroite (olivine, CaMnSiO4) from Franklin, New Jersey: Its composition, occurrence, and formation. American Mineralogist, 72 (3-4) 423-428
