Eudidymite

Na2Be2Si6O15 · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Edy
Discovered
1887
Also known as
  • Eudidymiet
  • Eudidymita

Where it forms, where it's found

Geological setting

Nepheline syenite

Type locality
Eudidymite locality
  1. Lille Arøya
  2. Larvik Commune
  3. Vestfold
  4. Norway
44recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · colorless
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (001), imperfect on(551)

Density
2.55 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 30° · 2V calc = 50°
Refractive index
1.545 – 1.551
Surface relief
Moderate
Principal indices
nα 1.545 · nβ 1.546 · nγ 1.551
Dispersion
r > v distinct
Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#10
Cell parameters
a = 12.6188(10) Å · b = 7.3781(5) Å · c = 13.9940(9) Å
Cell angles
β = 103.762(5) °
Ratio a:b:c
1 : 0.585 : 1.109
Unit cell volume
1265.47 ų
Z
4
Morphology

Crystals tabular on (001), spherulitic, micaceous, coarse and granular,massive.

Twinning

Twins on (001) common. V-shaped (Swallowtwins) twin

Type-locality form

Tabular crystals, usually twinned on (001)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
52.19%
14SiSiliconSilicon628.085168.510
34.35%
11NaSodiumSodium222.99045.980
9.37%
4BeBerylliumBeryllium29.01218.024
3.68%
1HHydrogenHydrogen21.0082.016
0.41%
Total490.514100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Ca

Synonyms

  • Eudidymiet
  • Eudidymita

In other languages

German
Eudidymit
Italian
Eudidimite · Eudidymite
Russian
Эвдидимит

Classification

Strunz
10th ed.

9.DG.60

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.60EudidymiteSpecies
Dana
8th ed.

66.03.01.03

  • 66Inosilicates Double-width, Unbranched Chains, (w=2)Class
  • 66.03Amphiboles - Ca-Na subgroupType
  • 66.03.01P=3Group
  • 66.03.01.03EudidymiteSpecies
CIM

14.3.6

  • 14Silicates not Containing AluminumClass
  • 14.3Silicates of BeGroup
  • 14.3.6EudidymiteSpecies

Group, growth & confusion

Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1887Brøgger, W.C. (1887) Om Eudidymit, et nyt norsk mineral. Foreløbig meddelelse [On Eudidymite, a new Norwegian mineral. Preliminary notice]. Nyt magazin for naturvidenskaberne [New magazine for the natural sciences], 31. Christiania [Oslo]. 196-199
  2. 1890Brøgger, Waldemar Christofer (1890) Die Mineralien der Syenitpegmatitgänge der südnorwegischen Augit- und Nephelinsyenite. Zeitschrift für Krystallographie und Mineralogie, 16 (1). 1-893
  3. 1899Flink, G (1899) Über einige seltene Mineralien aus der Gegend von Langesund in Norwegen [About some rare minerals from the Langesund area in Norway]. Bulletin of the Geological Institution of the University of Upsala, 4. 16-27
  4. 1929Zachariasen, W.H. (1929) Die feinbäliche Relation zwischen Eudidymit und Epididymit [The fine relation between eudidymite and epididymite]. Norsk Geologisk Tidsskrift [Norwegian Journal of Geology], 10 (3-4) 449-453
  5. 1933Palache, Charles (1933) Crystallographic Notes on Anapaite, Ainigmatite and Eudidymite. Zeitschrift für Kristallographie - Crystalline Materials, 86 (1) 280 doi:10.1524/zkri.1933.86.1.280DOI: 10.1524/zkri.1933.86.1.280
