Ferrierite-K

(K,Na)5(Si31Al5)O72 · 18H2O
IMA status
  • Approved
IMA symbol
Frr-K
Also known as
  • Ferrieriet-K

Where it forms, where it's found

Type locality
Santa Monica Mountains
  1. California
  2. USA
7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Silky

Optical

Optical type
Biaxial (+/-)
Refractive index
1.473 – 1.492
Surface relief
Low
Principal indices
nα 1.473 – 1.489 · nβ 1.474 – 1.489 · nγ 1.477 – 1.492
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0035
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]35 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation35 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Immm
Cell parameters
a = 18.973(7) Å · b = 14.140(6) Å · c = 7.478(4) Å
Ratio a:b:c
1 : 0.745 : 0.394
Z
1
Comment

Cell parameters from Wise and Tschernich 1976 sample #3.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen9015.9991439.910
51.57%
14SiSiliconSilicon3128.085870.635
31.18%
19KPotassiumPotassium539.098195.490
7.00%
13AlAluminiumAluminium526.982134.910
4.83%
11NaSodiumSodium522.990114.950
4.12%
1HHydrogenHydrogen361.00836.288
1.30%
Total2792.183100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ferrieriet-K

In other languages

German
Ferrierit-K
Italian
ferrierite-K
Chinese
钾碱沸石

Classification

Strunz
10th ed.

9.GD.50

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.50Ferrierite-KSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1976Wise, William S., Tschernich, R. W. (1976) Chemical composition of ferrierite. American Mineralogist, 61 (1-2) 60-66
  2. 1987Alberti, Alberto, Sabelli, Cesare (1987) Statistical and true symmetry of ferrierite: possible absence of straight Τ—Ο—Τ bridging bonds. Zeitschrift für Kristallographie, 178 (1-4). 249-256 doi:10.1524/zkri.1987.178.14.249 DOI: 10.1524/zkri.1987.178.14.249
  3. 1997Coombs, Douglas S., Alberti, Alberto, Armbruster, Thomas, Artioli, Gilberto, Colella, Carmine, Galli, Ermanno, Grice, Joel D., Liebau, Friedrich, Mandarino, Joseph A., Minato, Hideo, et al. (1997) Recommended nomenclature for zeolite minerals; report of the Subcommittee on Zeolites of the International Mineralogical Association, Commission on New Minerals and Mineral Names. The Canadian Mineralogist, 35 (6). 1571-1606
  4. 2011www.iza-online.org (n.d.) http://www.iza-online.org/natural/Datasheets/Ferrierite/ferrierite.html
