Ferrierite-Mg

[Mg2(K,Na)2Ca0.5](Si29Al7)O72 · 18H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Frr-Mg
Also known as
  • Ferrieriet-Mg

Where it forms, where it's found

Geological setting

Seams and vesicles in extrusive igneous rocks.

Type locality
Kamloops Lake
  1. Kamloops Mining Division
  2. British Columbia
  3. Canada

50.7359°, -120.5816°

33recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Silky
Transparency
Transparent · Translucent
Colour
White · colorless · pinkish · orange to red
Streak
White
Cleavage
Perfect

on (100)

Density
2.136 g/cm³

Optical

Optical type
Biaxial (+/-)
Refractive index
1.473 – 1.492
Surface relief
Low
Principal indices
nα 1.473 – 1.489 · nβ 1.474 – 1.489 · nγ 1.477 – 1.492
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0035
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]35 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation35 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pnnm
Cell parameters
a = 19.231(2) Å · b = 14.145(2) Å · c = 7.499(1) Å
Ratio a:b:c
1 : 0.736 : 0.390
Z
1
Morphology

Radiating groups of lath shaped crystals.

Comment

Cell parameters from Alberti and Sabelli, 1987.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen9015.9991439.910
53.88%
14SiSiliconSilicon2928.085814.465
30.48%
13AlAluminiumAluminium726.982188.874
7.07%
19KPotassiumPotassium239.09878.196
2.92%
12MgMagnesiumMagnesium224.30548.610
1.82%
11NaSodiumSodium222.99045.980
1.72%
1HHydrogenHydrogen361.00836.288
1.36%
20CaCalciumCalcium0.540.07820.039
0.75%
Total2672.362100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ferrieriet-Mg

In other languages

German
Ferrierit-Mg
Spanish
Ferrierita-Mg
Italian
ferrierite-Mg
Chinese
镁碱沸石

Classification

Strunz
10th ed.

9.GD.50

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.50Ferrierite-MgSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1918Graham, Richard Percival Devereux (1918) On Ferrierite, a New Zeolitic Mineral, from British Columbia: With Notes on Some Other Canadian Minerals, Proceedings and Transactions of the Royal Society of Canada, 3rd Session, Section IV, p. 185-190.
  2. 1966Vaughan, P. A. (1966) The crystal structure of the zeolite ferrierite. Acta Crystallographica, 21 (6) 983-990 doi:10.1107/s0365110x66004298DOI: 10.1107/s0365110x66004298
  3. 1969Wise, W. S., Nokleberg, W. J., Kokinos, M. (1969) Clinoptilolite and ferrierite from Agoura, California. American Mineralogist, 54 (5-6). 887-895
  4. 1983Orlandi, P.; Sabelli, C. (1983) Ferrierite from Monastir, Sardinia, Italy. Neues Jahrbuch für Mineralogie - Monatshefte, 1983. 489-504
  5. 1987Alberti, Alberto, Sabelli, Cesare (1987) Statistical and true symmetry of ferrierite: possible absence of straight Τ—Ο—Τ bridging bonds. Zeitschrift für Kristallographie, 178 (1-4). 249-256 doi:10.1524/zkri.1987.178.14.249 DOI: 10.1524/zkri.1987.178.14.249
