Ferripyrophyllite

Fe3+Si2O5(OH)
IMA status
  • Approved
IMA symbol
Fprl
Discovered
1978
IMA approved
1978
Also known as
  • Ferripyrophylliet
  • Ferripyrophyllita
  • IMA1978-062

Where it forms, where it's found

Type locality
Straßen shaft
  1. Eibenstock
  2. Erzgebirgskreis
  3. Saxony
  4. Germany
10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
brownish yellow
Tenacity
waxy
Density
2.97 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.65 – 1.688
Surface relief
High
Principal indices
nα 1.650 – 1.660 · nβ 1.676 – 1.678 · nγ 1.686 – 1.688
Pleochroism
Visible

X = Y = greenish; Z = bright yellow.

Dispersion
r < v weak
Michel-Lévy diagramhighlighted lineδ = 0.0320
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]320 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation320 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.26 Å · b = 9.1 Å · c = 10.01 Å
Cell angles
β = 95.5 °
Ratio a:b:c
1 : 1.730 : 1.903
Z
4
Comment

Space Group: n.d.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
45.93%
14SiSiliconSilicon228.08556.170
26.87%
26FeIronIron155.84555.845
26.72%
1HHydrogenHydrogen11.0081.008
0.48%
Total209.017100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • Ca
  • Al
  • K
  • Na

Synonyms

  • Ferripyrophylliet
  • Ferripyrophyllita
  • IMA1978-062

In other languages

German
Ferripyrophyllit · IMA 1978-062
Italian
Ferripirofillite · Ferripyrophyllite

Classification

Strunz
10th ed.

9.EC.10

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.ECPhyllosilicates with mica sheets, composed of tetrahedral and octahedral netsGroup
  • 9.EC.10FerripyrophylliteSpecies
Dana
8th ed.

71.02.01.02

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.02Sheets of 6-membered rings with 2:1 layersType
  • 71.02.01Pyrophyllite-talc groupGroup
  • 71.02.01.02FerripyrophylliteSpecies
CIM

14.19.5

  • 14Silicates not Containing AluminumClass
  • 14.19Silicates of FeGroup
  • 14.19.5FerripyrophylliteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. Mineralogical Abstracts: 31: 355-356.
  2. 1978Chukhrov F V, Zvyagin B B, Drits V A, Gorshkov A I, Ermilova L P, Goilo E A, Rudnitskaya E S (1978) The ferric analogue of pyrophyllite and related phases. Proceedings of the International Clay Conference, Oxford 1978, 55-64. [http://rruff.info/rruff_1.0/uploads/ICC1978_55.pdf]
  3. 1978Chukhrov F V, Zvyagin B B, Drits V A, Gorshkov A I, Ermilova L P, Goilo E A, Rudnitskaya E S (1978) The ferric analogue of pyrophyllite and related phases. Proceedings of the International Clay Conference, Oxford 1978, 55-64
  4. 1979Goilo, E.A. and Rudnizkaja, E.S. (1979) Über Ferripyrophyllit. Chemie der Erde: 38: 324-330.
  5. 1979Izvestiya Akademii nauk SSSR (1979): (2): 5-20.
