Ferro-actinolite

◻Ca2(Mg2.5-0.0Fe2+2.5-5.0)Si8O22(OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fact
Discovered
1946
Also known as
  • Ferro-actinoliet
  • Ferroactinolite
  • Ferrotremolite

Where it forms, where it's found

164recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Black-green · dark green
Streak
Greenish white
Tenacity
brittle
Cleavage
Distinct/Good

On (110), intersecting at 56° and 124°.

Density
3.24 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 10 – 12° · 2V calc = 88°
Refractive index
1.668 – 1.702
Surface relief
High
Principal indices
nα 1.668 · nβ 1.685 · nγ 1.702
Pleochroism
Visible

Moderate to strong, in yellows and greens.

Dispersion
r > v or r < v
Extinction
Y = b; Z ∧ c = 12.5°-17°.
Luminescence
Nonfluorescent
Notes

Absorption: Z > Y >= X.

Michel-Lévy diagramhighlighted lineδ = 0.0340
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]340 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation340 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.91 Å · b = 18.17 Å · c = 5.27 Å
Cell angles
β = 104.98 °
Ratio a:b:c
1 : 1.834 : 0.532
Z
4
Twinning

Simple or lamellar twinning parallel to (100).

Parting
Parting on (100).
Crystal structure

Chemical composition

Impurities
  • Ti
  • Al
  • Mn
  • Na
  • K
  • F
  • P

Synonyms

  • Ferro-actinoliet
  • Ferroactinolite
  • Ferrotremolite

In other languages

German
Ferro-Aktinolith
Italian
ferro-actinolite · Ferroactinolite

Classification

Strunz
10th ed.

9.DE.10

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.10Ferro-actinoliteSpecies
CIM

14.22.6

  • 14Silicates not Containing AluminumClass
  • 14.22Silicates of Fe and CaGroup
  • 14.22.6Ferro-actinoliteSpecies

Group, growth & confusion

In the same group
1 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1946Sundius, N. (1946) Sveriges Geologiska Undersökning Arsbok.
  2. 1998Mandarino, Joseph A. (1998) The Second List of Additions and Corrections to the Glossary of Mineral Species (1995) - The Amphibole Group. The Mineralogical Record, 29 (3) 169-174
  3. 1998Evans, Bernard W., Yang, Hexiong (1998) Fe-Mg order-disorder in tremolite-actinolite-ferro-actinolite at ambient and high temperature. American Mineralogist, 83 (5) 458-475 doi:10.2138/am-1998-5-606 DOI: 10.2138/am-1998-5-606
  4. 2000Verkouteren, Jennifer R., Wylie, Ann G. (2000) The tremolite-actinolite-ferro–actinolite series: Systematic relationships among cell parameters, composition, optical properties, and habit, and evidence of discontinuities. American Mineralogist, 85 (9) 1239-1254 doi:10.2138/am-2000-8-917 DOI: 10.2138/am-2000-8-917
  5. 2001(2001) Ferro-actinolite. Handbook of Mineralogy. Mineralogical Society of America
