Fluckite

CaMn2+(AsO3OH)2 · 2H2O
IMA status
  • Approved
IMA symbol
Fck
Discovered
1980
IMA approved
1978
Also known as
  • Fluckiet
  • IMA1978-054

Where it forms, where it's found

Type locality
Gabe Gottes Mine
  1. Sankt Jakob vein
  2. Neuenberg
  3. Sainte-Marie-aux-Mines
  4. Colmar-Ribeauvillé
  5. Haut-Rhin
  6. Grand Est
  7. France

48.2136°, 7.1589°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
colorless · pale pink · pale rose red
Streak
White
Tenacity
brittle
Cleavage
Perfect

{010| perfect, (100) good; (101) poor.

Optical

Optical type
Biaxial
Refractive index
1.618 – 1.642
Surface relief
Moderate
Principal indices
nα 1.618 · nβ 1.627 · nγ 1.642
Birefringence
0.024
Pleochroism
Non-pleochroic
Dispersion
r > v
UV response
Not fluorescent
Notes

2V = large.

Michel-Lévy diagramhighlighted lineδ = 0.0240
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]240 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation240 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 8.459 Å · b = 7.613 Å · c = 6.968 Å
Cell angles
α = 82.21 ° · β = 98.25 ° · γ = 95.86 °
Ratio a:b:c
1 : 0.900 : 0.824
Z
2
Morphology

Acicular, occasionally slender rod-like to prismatic. Dominant forms on type material are (100), (110), and (010).

Type-locality form

Radiating prismatic crystals.

Comment

Bull Min 103:129 (1980) structure

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
38.94%
33AsArsenicArsenic274.922149.844
36.47%
25MnManganeseManganese154.93854.938
13.37%
20CaCalciumCalcium140.07840.078
9.75%
1HHydrogenHydrogen61.0086.048
1.47%
Total410.898100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluckiet
  • IMA1978-054

In other languages

French
fluckite
German
Fluckit · IMA 1978-054
Spanish
fluckite
Italian
fluckite
Chinese
砷氢锰钙石

Classification

Strunz
10th ed.

8.CG

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CGFluckiteSpecies
Dana
8th ed.

39.01.02.01

  • 39Hydrated Acid Phosphates, Arsenates and VanadatesClass
  • 39.01A[HXO4]·xH2OType
  • 39.01.02— unnamed intermediate level —Group
  • 39.01.02.01FluckiteSpecies
CIM

20.8.13

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.8Arsenates of MnGroup
  • 20.8.13FluckiteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1980Bari, Hubert, Cesbron, Fabien, Permingeat, François, Pillard, François (1980) La fluckite, arséniate hydraté de calcium et manganèse CaMnH2(AsO4)2·2H2O, une nouvelle espèce minérale. Bulletin de Minéralogie, 103 (1) 122-128 doi:10.3406/bulmi.1980.7384DOI: 10.3406/bulmi.1980.7384
  2. 1980Catti, Michele, Chiari, Giacomo, Ferraris, Giovanni (1980) Fluckite, CaMn(HAsO4)2 • 2 H2O, a structure related by pseudo-polytypism to krautite MnHAsO4 • H2O. Bulletin de Minéralogie, 103 (1). 129-134 doi:10.3406/bulmi.1980.7385 DOI: 10.3406/bulmi.1980.7385
  3. 1980Fleischer, M., Cabri, L. J., Chao, G. Y., Pabst, A. (1980) New mineral names. American Mineralogist, 65 (9-10). 1065-1070
  4. 2005(2005) Fluckite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2017Ðorðević, Tamara, Gerger, Sabrina, Karanović, Ljiljana (2017) Hydrothermal and ionothermal synthesis of mineral-related arsenates in the system CdO–MO– As2O5 (M2+ = Mg, Co, Ni, Cu, Zn) and their crystal structures. European Journal of Mineralogy, 29 (1). 73-89 doi:10.1127/ejm/2017/0029-2585DOI: 10.1127/ejm/2017/0029-2585
