Ganophyllite

(K,Na)xMn2+6(Si,Al)10O24(OH)4 · nH2O (x = 1-2; n = 7-11)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gnp
Discovered
1890
Also known as
  • Ganophylliet
  • Ganophyllita

Where it forms, where it's found

Type locality
Harstigen Mine
  1. Pajsberg
  2. Persberg ore district
  3. Filipstad
  4. Värmland County
  5. Sweden

59.7853°, 14.3139°

38recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light brown · pale pink
Cleavage
Perfect

Perfect micaceous on (001); distinct on (100), (010)

Density
2.77 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = Small°
Refractive index
1.537 – 1.613
Surface relief
Moderate
Principal indices
nα 1.537 · nβ 1.611 · nγ 1.613
Pleochroism
Visible

Dark to pale yellow-brown.

Dispersion
weak, r < v
Notes

X ≃ c; Y ≃ a; Z = b.

Michel-Lévy diagramhighlighted lineδ = 0.0760
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]760 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation760 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 16.60 Å · b = 27.13 Å · c = 50.18 Å
Cell angles
β = 93.96 °
Ratio a:b:c
1 : 1.634 : 3.023
Z
8
Comment

Space Group: A2/a

Crystal structure

Chemical composition

Impurities
  • Fe
  • Zn
  • Pb
  • Ca
  • Ba

Synonyms

  • Ganophylliet
  • Ganophyllita

In other languages

French
Ganophyllite
German
Ganophyllit
Italian
Ganofillite · Ganophyllite

Classification

Strunz
10th ed.

9.EG.30

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EGDouble nets with 6-membered and larger ringsGroup
  • 9.EG.30GanophylliteSpecies
Dana
8th ed.

74.01.02.01

  • 74Phyllosilicates Modulated LayersClass
  • 74.01Modulated Layers with joined islandsType
  • 74.01.02Ganophyllite groupGroup
  • 74.01.02.01GanophylliteSpecies
CIM

16.16.9

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.16Aluminosilicates of MnGroup
  • 16.16.9GanophylliteSpecies

Group, growth & confusion

In the same group
2 members
Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1948Smith, W. Campbell, Bannister, F. A. (1948) Ganophyllite from the Benallt Mine, Rhiw, Carnarvonshire. Mineralogical Magazine and Journal of the Mineralogical Society, 28 (201) 343-352 doi:10.1180/minmag.1948.028.201.04 DOI: 10.1180/minmag.1948.028.201.04
  2. 1968Smith, Marie Lindberg, Frondel, Clifford (1968) The related layered minerals ganophyllite, bannisterite, and stilpnomelane. Mineralogical Magazine and Journal of the Mineralogical Society, 36 (283) 893-913 doi:10.1180/minmag.1968.283.036.01 DOI: 10.1180/minmag.1968.283.036.01
  3. 1978Jefferson, D. A. (1978) The crystal structure of ganophyllite, a complex manganese aluminosilicate. I. Polytypism and strutural variation. Acta Crystallographica Section A, 34 (4) 491-497 doi:10.1107/s0567739478001060DOI: 10.1107/s0567739478001060
  4. 1985Dunn, Pete J., Peacor, Donald R., Valley, John W., Randall, Charles A. (1985) Ganomalite from Franklin, New Jersey, and Jakobsberg, Sweden: new chemical and crystallographic data. Mineralogical Magazine, 49 (353). 579-582 doi:10.1180/minmag.1985.049.353.12 DOI: 10.1180/minmag.1985.049.353.12
  5. 1986Eggleton, Richard A., Guggenheim, Stephen (1986) A re-examination of the structure of ganophyllite. Mineralogical Magazine, 50 (356) 307-315 doi:10.1180/minmag.1986.050.356.18 DOI: 10.1180/minmag.1986.050.356.18
