Geikielite

MgTiO3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gk
Discovered
1892
Also known as
  • Geikieliet
  • Geikielit
  • Geikilithe

Where it forms, where it's found

Geological setting

Gem gravels.

Contact metamorphism of impure magnesian limestones.

Type locality
Rakwana
  1. Ratnapura District
  2. Sabaragamuwa Province
  3. Sri Lanka

6.4647°, 80.6160°

67recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Black · red · brownish black
Streak
Purple brown
Cleavage
Distinct/Good

On (1011)

Fracture
Conchoidal · Sub-Conchoidal
Density
3.79 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.95 – 2.35
Surface relief
Very high
Principal indices
nω 2.31 – 2.35 · nε 1.95 – 1.98
Pleochroism
Weak

O = Pinkish red E = Brownish to purplish red

Optical colour
Gray
Anisotropism
Strong
Internal reflections
Red
Michel-Lévy diagramhighlighted lineδ = 0.3650
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]3650 nm7th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation3650 nm
Order7th order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#78
Cell parameters
a = 5.05478(26) Å · c = 13.8992(7) Å
Z
6
Morphology

Tabular to prismatic crystals.

Type-locality form

Pebbles.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen315.99947.997
39.94%
22TiTitaniumTitanium147.86747.867
39.83%
12MgMagnesiumMagnesium124.30524.305
20.23%
Total120.169100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Cr
  • Mn
  • Ca

Synonyms

  • Geikieliet
  • Geikielit
  • Geikilithe

In other languages

French
geikielite
German
Geikielith
Spanish
Geikielita
Italian
geikielite
Japanese
ゲイキー石
Chinese
镁钛矿

Classification

Strunz
10th ed.

4.CB.05

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CBWith medium-sized cationsGroup
  • 4.CB.05GeikieliteSpecies
Dana
8th ed.

04.03.05.02

  • 04Simple OxidesClass
  • 04.03A2X3Type
  • 04.03.05Ilmenite GroupGroup
  • 04.03.05.02GeikieliteSpecies
CIM

7.9.5

  • 7Oxides and HydroxidesClass
  • 7.9Oxides of TiGroup
  • 7.9.5GeikieliteSpecies

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 1892Fletcher, L. (1892) Geikielite and Baddeleyite, two new mineral species. Nature: 46(1200): 620-621.
  2. 1893Dick, A. (1893) On Geikielite, a New Mineral from Ceylon. Mineralogical Magazine and Journal of the Mineralogical Society, 10 (46) 145-147 doi:10.1180/minmag.1893.010.46.07 DOI: 10.1180/minmag.1893.010.46.07
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1955Swanson, H.E., Gilfrich, N.T., Ugrinic, G.M. (1955) Standard X-ray Diffraction Powder Patterns. United States Department of Commerce, National Bureau of Standards Circular 539, vol 5, 75 pgs (43).
  5. 1966Chao, G.Y., Hounslow, A.W. (1966) Abstract of paper presented at the eleventh annual meeting: The first Canadian occurrence of geikielite. The Canadian Mineralogist, 8, 664-664.
