Gerhardtite

Cu2(NO3)(OH)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ghd
Discovered
1885
Also known as
  • Gerhardtiet

Where it forms, where it's found

Geological setting

Oxidation zone of copper deposits

Type locality
United Verde Mine
  1. Jerome
  2. Verde Mining District
  3. Black Hills (Black Hill Range)
  4. Yavapai County
  5. Arizona
  6. USA

34.7500°, -112.1222°

24recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Emerald Green
Streak
Light green
Tenacity
flexible
Cleavage
Perfect

On (001) perfect; on (100) good.

Density
3.4 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 85° · 2V calc = 86°
Refractive index
1.703 – 1.722
Surface relief
High
Principal indices
nα 1.703 · nβ 1.713 · nγ 1.722
Birefringence
0.019
Pleochroism
Visible

X = Green Y = Green Z = Blue

Dispersion
r < v very strong
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#44
Cell parameters
a = 6.087(2) Å · b = 13.813(4) Å · c = 5.597(2) Å
Ratio a:b:c
1 : 2.269 : 0.920
Z
4
Morphology

Crystals thick tabular (001). Strongly striated on the pyramid zone. Faces often in oscillatory combination. Crystals flexible, with separation along (100).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper263.546127.092
52.93%
8OOxygenOxygen615.99995.994
39.98%
7NNitrogenNitrogen114.00714.007
5.83%
1HHydrogenHydrogen31.0083.024
1.26%
Total240.117100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gerhardtiet

In other languages

German
Gerhardtit
Italian
Gerhardtite
Chinese
铜硝石

Classification

Strunz
10th ed.

5.NB.05

  • 5CarbonatesClass
  • 5.NNITRATESDivision
  • 5.NBWith OHGroup
  • 5.NB.05GerhardtiteSpecies
Dana
8th ed.

19.01.01.01

  • 19Nitrates Containing Hydroxyl or HalogenClass
  • 19.01Anhydrous Nitrates Containing Hydroxyl or HalogenType
  • 19.01.01— unnamed intermediate level —Group
  • 19.01.01.01GerhardtiteSpecies
CIM

13.3

  • 13NitratesClass
  • 13.3— unnamed intermediate level —Group
  • 13.3GerhardtiteSpecies

Group, growth & confusion

Often grow together
2 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. Helv. Chim. Acta: 35: 375-390.
  2. 1885Wells and Penfield (1885) American Journal of Science: 30: 50.
  3. 1904Lindgren, W.; Hillebrand, W.F. (1904) Minerals from the Clifton-Morenci district. American Journal of Science: 18: 448-460.
  4. 1923Thoreau (1923) Société géologique de Belgique, Liége, Annales: 46: B 285.
  5. 1934Larsen, E.S.; Berman, H. (1934) The microscopic determination of the nonopaque minerals. Bulletin of the US Geological Survey Vol. 848. US Geological Survey p.1-266. doi:10.3133/b848 DOI: 10.3133/b848
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Gerhardtite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/gerhardtite-1680},
  note      = {Accessed 2026-05-11}
}
