Greenalite

(Fe2+,Fe3+)2-3Si2O5(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gre
Discovered
1903
Also known as
  • Greenaliet
  • Greenalit

Where it forms, where it's found

Geological setting

banded iron formation

Type locality
Biwabik
  1. Saint Louis County
  2. Minnesota
  3. USA
60recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
green · light yellow-green
Streak
greenish-gray
Density
2.85 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.65 – 1.675
Surface relief
High
Principal indices
nα 1.65 – 1.675 · nβ 1.674 · nγ 1.674
Pleochroism
Visible

Pale yellow to green

Dispersion
weak
Notes

Isotropic when fine grained. n = 1.670

Michel-Lévy diagramhighlighted lineδ = 0.0115
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]115 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation115 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.54 Å · b = 9.55 Å · c = 7.44 Å
Cell angles
β = 104.33 °
Ratio a:b:c
1 : 1.724 : 1.343
Z
2
Morphology

oolitic to microcrystalline

Comment

Point Group: n.d.; Space Group: n.d.

Crystal structure

Chemical composition

Impurities
  • Al
  • Mn
  • Mg

Synonyms

  • Greenaliet
  • Greenalit

In other languages

French
Greenalite
German
Greenalith
Italian
Greenalite

Classification

Strunz
10th ed.

9.ED.15

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EDPhyllosilicates with kaolinite layers composed of tetrahedral and octahedral netsGroup
  • 9.ED.15GreenaliteSpecies
Dana
8th ed.

71.01.2b.04

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.01Sheets of 6-membered rings with 1:1 layersType
  • 71.01.2b— unnamed intermediate level —Group
  • 71.01.2b.04GreenaliteSpecies
CIM

14.19.6

  • 14Silicates not Containing AluminumClass
  • 14.19Silicates of FeGroup
  • 14.19.6GreenaliteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. Rasmussen, M. G., Evans, B. W., Kuehner, S. M. (1998). Low-temperature fayalite, greenalite, and minnesotaite from the Overlook gold deposit, Washington: phase relations in the system FeO-SiO2-H2O. The Canadian Mineralogist, 36 (1), 147-162.
  2. Guggenheim, Stephen, Bailey, Sturges W. (1989) An occurrence of a modulated serpentine related to the greenalite-caryopilite series. American Mineralogist, 74 (5-6) 637-641
  3. 1903Leith, C.K. (1903) The Mesabi iron-bearing district of Minnesota. Section II. The Biwabik Formation (iron-bearing). Monographs of the United States Geological Survey: 43: 100-115.
  4. 1935Jolliffe, Fred (1935) A study of greenalite. American Mineralogist, 20 (6) 405-425
  5. 1936Gruner, John W. (1936) The structure and chemical composition of greenalite. American Mineralogist, 21 (7) 449-455
