Odinite

(Fe3+,Mg,Al,Fe2+)2.5(Si,Al)2O5(OH)4
IMA status
  • Approved
IMA symbol
Odn
IMA approved
1988
Also known as
  • IMA1988-015

Where it forms, where it's found

Geological setting

Recent sediments on continental margins.

Type locality
Los Archipelago (Los Islands)
  1. Conakry Region
  2. Guinea
3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silky green to dark green
Streak
Gray green

Optical

Optical type
Biaxial
Dispersion
r > v strong

Crystallography

Crystal system
Monoclinic
Space group
Cm
Comment

1M (Cm) and 1A (P31m) polytypes.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron555.845279.225
41.95%
8OOxygenOxygen915.999143.991
21.63%
13AlAluminiumAluminium4.526.982121.419
18.24%
12MgMagnesiumMagnesium2.524.30560.763
9.13%
14SiSiliconSilicon228.08556.170
8.44%
1HHydrogenHydrogen41.0084.032
0.61%
Total665.600100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1988-015

In other languages

French
Odinite
German
IMA 1988-015 · Odinit
Spanish
Odinita
Italian
Odinite

Classification

Strunz
10th ed.

9.ED.05

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EDPhyllosilicates with kaolinite layers composed of tetrahedral and octahedral netsGroup
  • 9.ED.05OdiniteSpecies
Dana
8th ed.

71.01.01.05

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.01Sheets of 6-membered rings with 1:1 layersType
  • 71.01.01Kaolinite groupGroup
  • 71.01.01.05OdiniteSpecies
CIM

16.19.16

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.19Aluminosilicates of Fe and MgGroup
  • 16.19.16OdiniteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1988Bailey, S. W. (1988) Odinite, a new dioctahedral-trioctahedral Fe3+-rich 1:1 clay mineral. Clay Minerals, 23 (3) 237-247 doi:10.1180/claymin.1988.023.3.01DOI: 10.1180/claymin.1988.023.3.01
  2. 1990American Mineralogist (1990): 75: 432-433.
  3. 2001(2001) Odinite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2022Piercy, J.D., Bridges, J.C., Hicks, L.J. (2022) Carbonate dissolution and replacement by odinite and saponite in the Lafayette nakhlite: Part of the CO2-CH4 cycle on Mars?. Geochimica et Cosmochimica Acta, 326. 97-118 doi:10.1016/j.gca.2022.02.003DOI: 10.1016/j.gca.2022.02.003
