Hendersonite

Ca1.3(V5+,V4+)6O16 · 6H2O
IMA status
  • Approved
IMA symbol
Hdr
Discovered
1962
Also known as
  • Hendersoniet
  • Jayjayite

Where it forms, where it's found

Geological setting

Partially oxidized uranium ore.

Type locality
Nelson Point mine
  1. Eastside mines
  2. Shiprock District
  3. San Juan County
  4. New Mexico
  5. USA

36.7153°, -109.0333°

8recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark greenish black to black · turning brown on exposure to air.
Tenacity
sectile
Cleavage
Perfect

parallel to platiness

Density
2.77 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
2 – 2.1
Surface relief
Very high
Principal indices
nα 2 · nβ 2.1 · nγ 2.1
Pleochroism
Visible

absorption is X yellow green, Y green, and Z yellow brown to brown.

Dispersion
relatively weak
Notes

α = < 2.01 β = > 2.01 γ = > 2.01 2V(meas.) = Medium.

Michel-Lévy diagramhighlighted lineδ = 0.1000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1000 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1000 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 12.40(4) Å · b = 18.92(8) Å · c = 10.77(3) Å
Ratio a:b:c
1 : 1.526 : 0.869
Z
3
Morphology

microscopic fibers or blades, more rarely as elongated six-sided platy crystals; in bundles of fibers or subparallel aggregates

Type-locality form

aggregates of microscopic bladed to fibrous crystals

Comment

Point Group: 2/m2/m2/m or mm2; Space Group: Pnam or Pna21

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
23VVanadiumVanadium1250.942611.304
59.49%
8OOxygenOxygen2215.999351.978
34.26%
20CaCalciumCalcium1.340.07852.101
5.07%
1HHydrogenHydrogen121.00812.096
1.18%
Total1027.479100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hendersoniet
  • Jayjayite

In other languages

German
Hendersonit
Italian
Hendersonite
Chinese
复钒钙石

Classification

Strunz
10th ed.

4.HG.50

  • 4OxidesClass
  • 4.HV[5,6] VanadatesDivision
  • 4.HGUnclassified V oxidesGroup
  • 4.HG.50HendersoniteSpecies
Dana
8th ed.

47.03.01.04

  • 47Vanadium OxysaltsClass
  • 47.03Hydrated Normal Vanadium OxysaltsType
  • 47.03.01Hewettite GroupGroup
  • 47.03.01.04HendersoniteSpecies
CIM

21.2.6

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.2Vanadates of Mg, Ca, Sr or BaGroup
  • 21.2.6HendersoniteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1962Lindberg, M. L., Weeks, A. D., Thompson, M. E., Elston, D. P., Meyrowitz, Robert (1962) Hendersonite, a new calcium vanadyl vanadate from Colorado and New Mexico. American Mineralogist, 47 (11-12) 1252-1272
  2. 1963Fleischer, Michael (1963) New Mineral Names. American Mineralogist, 48 (3-4) 433-436
  3. 1990Evans, Howard T., Jr.,, Hughes, John M. (1990) Crystal chemistry of the natural vanadium bronzes. American Mineralogist, 75 (5-6) 508-521
  4. 2005(2005) Hendersonite. Handbook of Mineralogy. Mineralogical Society of America
