Hydroboracite

CaMg[B3O4(OH)3]2 · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hbo
Discovered
1834
Also known as
  • Hydroboraciet

Where it forms, where it's found

Geological setting

The original description of the type locality is the Caucasus. The original location has not been found.

Type locality
Inder B deposit and salt dome
  1. Inder District
  2. Atyrau Region
  3. Kazakhstan

48.5167°, 51.9500°

35recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white
Cleavage
Perfect

(010), perfect; (100), distinct.

Density
2.15 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 60 – 66° · 2V calc = 62 – 66°
Refractive index
1.52 – 1.571
Surface relief
Moderate
Principal indices
nα 1.520 – 1.523 · nβ 1.534 – 1.535 · nγ 1.569 – 1.571
Dispersion
relatively weak r < v
Michel-Lévy diagramhighlighted lineδ = 0.0485
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]485 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation485 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P1 1 2/b
Cell parameters
a = 11.769(2) Å · b = 6.684(2) Å · c = 8.235(4) Å
Cell angles
β = 102.59(2) °
Ratio a:b:c
1 : 0.568 : 0.700
Z
2
Morphology

Crystals elongated [001] and flattened (010). Lamellar-fibrous radiating or columnar. Compact and fine-grained.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1715.999271.983
65.80%
5BBoronBoron610.81064.860
15.69%
20CaCalciumCalcium140.07840.078
9.70%
12MgMagnesiumMagnesium124.30524.305
5.88%
1HHydrogenHydrogen121.00812.096
2.93%
Total413.322100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hydroboraciet

In other languages

French
Hydroboracite
German
Hydroboracit
Spanish
Hidroboracita
Italian
Hydroboracite · Idroboracite
Russian
Гидроборацит

Classification

Strunz
10th ed.

6.CB.15

  • 6BoratesClass
  • 6.CTriboratesDivision
  • 6.CBIno-triboratesGroup
  • 6.CB.15HydroboraciteSpecies
Dana
8th ed.

26.03.06.01

  • 26Hydrated Borates Containing Hydroxyl or HalogenClass
  • 26.03TriboratesType
  • 26.03.06— unnamed intermediate level —Group
  • 26.03.06.01HydroboraciteSpecies
CIM

9.3.22

  • 9BoratesClass
  • 9.3Borates of Ca and SrGroup
  • 9.3.22HydroboraciteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1834Hess H (1834) Der hydroboracit, eine neue mineralspecies. Annalen der Physik und Chemie 31, 49-53
  2. 1865Lottner (1865) Zeitschrift der Deutsche geologische Gesellschaft, Berlin: 17: 430.
  3. 1907Erdmann (1907) Chemie und Industrie der Kalisalze, Berlin: 12.
  4. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  5. 1928Schaller (1928) Festsch. Goldschmidt, Heidelberg: 256.
