Inyoite

CaB3O3(OH)5 · 4H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Iyo
Discovered
1914
Also known as
  • Inyoiet

Where it forms, where it's found

Geological setting

Borate evaporite deposit.

Type locality
Monte Blanco Mine
  1. Monte Blanco
  2. Black Mountains
  3. Amargosa Range
  4. Inyo County
  5. California
  6. USA

36.3794°, -116.7678°

25recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · turning white upon partial dehydration · colourless in transmitted light
Tenacity
brittle
Cleavage
Distinct/Good

On (001) good; on (010) quality unstated.

Fracture
Irregular/Uneven
Density
1.875 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70 – 86° · 2V calc = 70 – 80°
Refractive index
1.49 – 1.52
Surface relief
Moderate
Principal indices
nα 1.490 – 1.495 · nβ 1.501 – 1.505 · nγ 1.516 – 1.520
Dispersion
relatively weak
Michel-Lévy diagramhighlighted lineδ = 0.0255
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]255 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation255 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 10.621(1) Å · b = 12.066(1) Å · c = 8.408(1) Å
Cell angles
β = 114.03 °
Ratio a:b:c
1 : 1.136 : 0.792
Z
4
Morphology

Crystals short prismatic [001] to tabular (001), with (110) and (001) dominant. Massive granular; coarse spherulitic aggregates.

Type-locality form

Large intergrown rhombs, glassy and clear when fresh, but altering / pseudomorphing to meyerhofferite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
69.16%
20CaCalciumCalcium140.07840.078
14.44%
5BBoronBoron310.81032.430
11.68%
1HHydrogenHydrogen131.00813.104
4.72%
Total277.600100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Inyoiet

In other languages

French
inyoite
German
Inyoit
Spanish
Inyoíta
Italian
Inyoite

Classification

Strunz
10th ed.

6.CA.35

  • 6BoratesClass
  • 6.CTriboratesDivision
  • 6.CANeso-triboratesGroup
  • 6.CA.35InyoiteSpecies
Dana
8th ed.

26.03.01.01

  • 26Hydrated Borates Containing Hydroxyl or HalogenClass
  • 26.03TriboratesType
  • 26.03.01Inyoite GroupGroup
  • 26.03.01.01InyoiteSpecies
CIM

9.3.12

  • 9BoratesClass
  • 9.3Borates of Ca and SrGroup
  • 9.3.12InyoiteSpecies

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 1916Schaller, Waldemar T. (1916) Inyoite and meyerhofferite, two new calcium borates. United States Geological Survey Bulletin 610 (Mineralogical Notes Series 3): 35-55. https://pubs.usgs.gov/bul/0610/report.pdf
  2. 1919Rogers, Austin F. (1919) Colemanite pseudomorphous after inyoite from Death Valley, California. American Mineralogist, 4 (11) 135-139
  3. 1921Poitevin, E., Ellsworth, H.V. (1921) Inyoite from New Brunswick. Geological Survey of Canada, Museum Bulletin 32, 26 pages.
  4. 1936Boldyreva, A.M. (1936) Hydroboracite and inyoite of Inder mountains (western Kazakhstan). Tsentral'. nauchno-issled. geol.-razved. inst. Materialy, 1, 62-65 [in Russian]. (Min. Abs. (1936): 6: 336).
  5. 1937Boky (1937) Bulletin de Académy des sciences de l'Union des Républiques Soviétiques Socialistes, Cl. sc. mat. nat., Ser. chim.: 871.
