Iraqite-(La)

KCa2(La,Ce,Th)Si8O20
IMA status
  • Approved
IMA symbol
Irq-La
Also known as
  • IMA1973-041
  • Irakit-(La)
  • Iraqiet-(La)

Where it forms, where it's found

Type locality
Shakhi-Rash Mountain
  1. Hero
  2. Qaladiza
  3. Pshdar District
  4. Sulaymaniyah Governorate
  5. Iraq

Radioactivity

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Pale greenish yellow
Streak
Whitish
Cleavage
Distinct/Good

Two good cleavages and a third poor cleavage

Fracture
Irregular/Uneven
Density
3.27 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.585 – 1.59
Surface relief
Moderate
Principal indices
nω 1.590 · nε 1.585
UV response
None (LW or SW)
Notes

anomalously biaxial

Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
P4/mcc
Cell parameters
a = 7.61(1) Å · c = 14.72(2) Å
Z
1
Morphology

Anhedral, massive.

Comment

(by analogy to ekanite).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
27.23%
90ThThoriumThorium1232.038232.038
19.75%
14SiSiliconSilicon828.085224.680
19.12%
58CeCeriumCerium1140.116140.116
11.93%
57LaLanthanumLanthanum1138.905138.905
11.82%
20CaCalciumCalcium240.07880.156
6.82%
19KPotassiumPotassium139.09839.098
3.33%
Total1174.973100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1973-041
  • Irakit-(La)
  • Iraqiet-(La)

In other languages

German
IMA 1973-041 · Iraqit-(La)
Italian
Iraqite- · Iraqite-(La)

Classification

Strunz
10th ed.

9.CH.10

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CH[Si4O12]8- 4-membered double ringsGroup
  • 9.CH.10Iraqite-(La)Species
Dana
8th ed.

63.01.01.02

  • 63Cyclosilicates Condensed RingsClass
  • 63.01Condensed Rings (Steacyite group)Type
  • 63.01.01Steacyite GroupGroup
  • 63.01.01.02Iraqite-(La)Species
CIM

14.8.8

  • 14Silicates not Containing AluminumClass
  • 14.8Silicates of Group III metals other than AlGroup
  • 14.8.8Iraqite-(La)Species

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1976Fleischer, Michael, Pabst, Adolf, Cabri, Louis J. (1976) New Mineral Names. American Mineralogist, 61 (9-10) 1053-1056
  2. 1976Livingstone, A., Atkin, D., Hutchison, D., Al-Hermezi, H. M. (1976) Iraqite, a new rare-earth mineral of the ekanite group. Mineralogical Magazine, 40 (313) 441-445 doi:10.1180/minmag.1976.040.313.02 DOI: 10.1180/minmag.1976.040.313.02
  3. 1982Perrault, G., Szymański, J. T. (1982) Steacyite, a new name and a re-evaluation of the nomenclature of "ekanite"-group minerals. The Canadian Mineralogist, 20 (1) 59-63
  4. 2001(2001) Iraqite-(La). Handbook of Mineralogy. Mineralogical Society of America
