Jahnsite-(MnMnFe)

Mn2+Mn2+Fe2+2Fe3+2(PO4)4(OH)2 · 8H2O
IMA status
  • Approved
IMA symbol
Jah-MnMnFe
IMA approved
2018
Also known as
  • IMA2018-096
  • Jahnsiet-(MnMnFe)

Where it forms, where it's found

Type locality
Malpensata pegmatitic dyke (Olgiasca-Malpensata
  1. Croce Quarry
  2. Secondi dyke)
  3. Piona Peninsula
  4. Colico
  5. Lecco Province
  6. Lombardy
  7. Italy

46.1214°, 9.3233°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Dark brown
Streak
Pale greenish brown
Tenacity
brittle
Cleavage
Distinct/Good

(001)

Density
2.654 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = 60°
Refractive index
1.673 – 1.689
Surface relief
High
Principal indices
nα 1.673 · nβ 1.685 · nγ 1.689
Pleochroism
Non-pleochroic
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0160
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]160 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation160 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/a
Cell parameters
a = 14.6983(6) Å · b = 7.1477(2) Å · c = 10.0209(4) Å
Ratio a:b:c
1 : 0.486 : 0.682
Unit cell volume
107.13 ų
Z
2
Type-locality form

weakly flattened on (010), and twinned by reflection on (001), up to 130 μm in size.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2615.999415.974
46.67%
26FeIronIron455.845223.380
25.06%
15PPhosphorusPhosphorus430.974123.896
13.90%
25MnManganeseManganese254.938109.876
12.33%
1HHydrogenHydrogen181.00818.144
2.04%
Total891.270100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2018-096
  • Jahnsiet-(MnMnFe)

In other languages

German
IMA 2018-096 · Jahnsit-(MnMnFe)
Italian
Jahnsite- · Jahnsite-(MnMnFe)

Classification

Strunz
10th ed.

8.DH.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DHWith large and medium-sized cations, (OH, etc.):RO4 < 1:1Group
  • 8.DH.15Jahnsite-(MnMnFe)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 2014Baijot, Maxime, Hatert, Frédéric, Dal Bo, Fabrice, Philippo, Simon (2014) Mineralogy and petrography of phosphate mineral association from the Jocão pegmatite, Minas Gerais, Brazil. The Canadian Mineralogist, 52 (2) 373-397 doi:10.3749/canmin.52.2.373DOI: 10.3749/canmin.52.2.373
  2. 2018Hålenius, Ulf, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2018) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) NEWSLETTER 46. European Journal of Mineralogy, 30 (6) 1181-1189 doi:10.1127/ejm/2018/0030-2819DOI: 10.1127/ejm/2018/0030-2819
  3. 2019Vignola, Pietro, Hatert, Frédéric, Rotiroti, Nicola, Nestola, Fabrizio, Risplendente, Andrea, Vanini, Francesco (2019) Jahnsite-(MnMnFe), Mn2+Mn2+Fe2+2Fe3+2(PO4)4(OH)2·8H2O, a new phosphate mineral from the Malpensata pegmatite, Olgiasca, Colico Municipality, Lecco Province, Italy. The Canadian Mineralogist, 57 (2) 225-233 doi:10.3749/canmin.1800077DOI: 10.3749/canmin.1800077
  4. 2021(2021) Jahnsite-(MnMnFe). Handbook of Mineralogy. Mineralogical Society of America
