Jôkokuite

Mn2+(SO4) · 5H2O
IMA status
  • Approved
IMA symbol
Jôk
Discovered
1978
Also known as
  • IMA1976-045

Where it forms, where it's found

Geological setting

Efflorescences in oxidized portions of mine workings.

Type locality
Johkoku mine (Jôkoku mine
  1. Jokoku mine)
  2. Kaminokuni
  3. Hiyama District
  4. Hiyama Subprefecture
  5. Hokkaidō Prefecture
  6. Japan

41.6667°, 140.0528°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pale pink

Colorless in thin section.

Streak
White
Cleavage
None Observed
Density
2.03 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70 – 80° · 2V calc = 74°
Refractive index
1.498 – 1.517
Surface relief
Moderate
Principal indices
nα 1.498 · nβ 1.510 · nγ 1.517
Dispersion
very weak
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.37 Å · b = 10.77 Å · c = 6.13 Å
Cell angles
α = 98.77 ° · β = 109.95 ° · γ = 75.03 °
Ratio a:b:c
1 : 1.691 : 0.962
Z
2
Morphology

Massive stalactitic, to 5 cm long.

Type-locality form

Stalactites, up to about 5 cm long and 1 cm across, composed of irregular and fine-grained crystals with a mozaic texture. Individual grains are less than 0.05 mm across.

Comment

Space Group: by analogy to chalcanthite

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
59.73%
25MnManganeseManganese154.93854.938
22.79%
16SSulfurSulfur132.06032.060
13.30%
1HHydrogenHydrogen101.00810.080
4.18%
Total241.069100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1976-045

In other languages

French
jôkokuite
German
IMA 1976-045 · Jôkokuit
Italian
Jôkokuite
Japanese
上国石
Chinese
上国石 · 五水錳礬

Classification

Strunz
10th ed.

7.CB.20

  • 7SulfatesClass
  • 7.CSulfates (selenates, etc.) without additional anions, with H2ODivision
  • 7.CBWith only medium-sized cationsGroup
  • 7.CB.20JôkokuiteSpecies
Dana
8th ed.

29.06.07.04

  • 29Hydrated Acid and Normal SulfatesClass
  • 29.06AXO4·xH2OType
  • 29.06.07Chalchanthite Group (Triclinic: P-1)Group
  • 29.06.07.04JôkokuiteSpecies
CIM

25.9.2

  • 25SulphatesClass
  • 25.9Sulphates of MnGroup
  • 25.9.2JôkokuiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1978Nambu, Matsuo, Tanida, Katsutoshi, Kitamura, Tsuyoshi, Kato, Eiichi (1978) Jôkokuite, MnSO4·5H2O, a new mineral from the Jôkoku Mine, Hokkaido, Japan. Mineralogical Journal, 9 (1) 28-38 doi:10.2465/minerj.9.28DOI: 10.2465/minerj.9.28
  2. 1979Fleischer, Michael, Chao, George Y., Mandarino, J. A. (1979) New mineral names. American Mineralogist, 64 (5-6) 652-659
  3. 1982Caminiti, R., Marongiu, G., Paschina, G. (1982) A comparative X-ray diffraction study of aqueous MnSO4 and crystals of MnSO4·5H2O. Zeitschrift für Naturforschung A Physical Science: 37: 581-586.
  4. 2005(2005) Jôkokuite. Handbook of Mineralogy. Mineralogical Society of America
