Kelyanite

Hg12SbO6BrCl2
IMA status
  • Approved
IMA symbol
Kyn
Discovered
1981
IMA approved
1981
Also known as
  • IMA1981-013
  • Kelyaniet

Where it forms, where it's found

Geological setting

Alteration zone of mercury deposit

Type locality
Kelyana Hg Deposit
  1. Middle Kelyana River
  2. North-Muya Range
  3. Baunt District
  4. Buryatia
  5. Russia

Safety & handling

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
reddish brown
Streak
brownish red, cherry red
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
8.51 g/cm³

Optical

Pleochroism
Visible

reddish brown to pale brown

Optical colour
grayish white
Anisotropism
noted
Bireflectance
weak
Internal reflections
deep brownish red to deep red
Tropism
Anisotropic
Reflectance R%
(20.5,19.9) 460, (18.9,18.1) 546, (17.8,17.1) 620
Reflected-light panel
19.1 %anisotropic · dual curve
Specimen sRGB 157, 111, 64
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
weak
Anisotropism
noted
Reflected colour
grayish white
Internal reflections
deep brownish red to deep red

Crystallography

Crystal system
Trigonal
Space group
#75
Cell parameters
a = 13.560(4) Å · c = 10.004(6) Å
Z
3
Morphology

Irregular grains

Twinning

None observed in type material

Type-locality form

Irregular grains up to 1-2 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
80HgMercuryMercury12200.5922407.104
86.72%
51SbAntimonyAntimony1121.760121.760
4.39%
8OOxygenOxygen615.99995.994
3.46%
35BrBromineBromine179.90479.904
2.88%
17ClChlorineChlorine235.45070.900
2.55%
Total2775.662100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1981-013
  • Kelyaniet

In other languages

German
IMA 1981-013 · Kelyanit
Italian
Kelyanite

Classification

Strunz
10th ed.

3.DD.60

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DDWith HgGroup
  • 3.DD.60KelyaniteSpecies
Dana
8th ed.

10.06.11.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.06AmBn(O,OH)pXqType
  • 10.06.11— unnamed intermediate level —Group
  • 10.06.11.01KelyaniteSpecies
CIM

8.9.2

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.9Halides of Sb and BiGroup
  • 8.9.2KelyaniteSpecies

Group, growth & confusion

Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1982Vasilev, V.I., Lavrent´ev, Y.G., Pal´chik, N.A. (1982) Kelyanite, Hg36Sb3(Cl,Br)9O28, a new mineral. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 111(3): 330-334.
  2. 1983Dunn, P. J., Fleischer, M., Chao, G. Y., Cabri, L. J., Mandarino, J. A. (1983) New mineral names. American Mineralogist, 68 (11-12) 1248-1252
  3. 1983Vasil'yev, V. I.; Lavrent'yev, Yu. G.; Pal'chik, N. A. (1983) Kelyanite, Hg36Sb3(Cl, Br)9028 - a new mineral. International Geology Review, 25 (7). 864-868 doi:10.1080/00206818309466777DOI: 10.1080/00206818309466777
  4. 2008Pervukhina, N. V., Borisov, S. V., Magarill, S. A., Naumov, D. Yu., Vasil'ev, V. I. (2008) The crystal structure of kelyanite, (Hg2)6(SbO6)BrCl2. American Mineralogist, 93 (10) 1666-1669 doi:10.2138/am.2008.2876 DOI: 10.2138/am.2008.2876
  5. 2021(2021) Kelyanite. Handbook of Mineralogy. Mineralogical Society of America
