Kobellite

Pb11(Cu,Fe)2(Bi,Sb)15S35
IMA status
  • Approved
  • Grandfathered
IMA symbol
Kbl
Discovered
1839

Where it forms, where it's found

Geological setting

High temperature hydrothermal deposits.

Type locality
Vena Mines
  1. Hammar
  2. Askersund
  3. Örebro County
  4. Sweden

58.8852°, 15.0422°

127recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Blackish lead-gray to steel-gray

May tarnish with a blue iridescence

Streak
Black
Cleavage
Distinct/Good

good on 010

Fracture
Irregular/Uneven
Density
6.334 g/cm³

Optical

Pleochroism
Weak
Optical colour
White
Anisotropism
Distinct
Tropism
Anisotropic
Reflectance R%
(48.6,51.8) 400, (48.0,51.1) 420, (47.5,50.5) 440, (47.0,49.9) 460, (46.6,49.3) 480, (46.1,48.7) 500, (45.6,48.1) 520, (45.0,47.5) 540, (44.6,46.9) 560, (44.1,46.4) 580, (43.8,45.9) 600, (43.5,45.7) 620, (43.3,45.5) 640, (43.1,45.4) 660, (42.9,45.3) 680, (42.7,45.2) 700
UV response
Not fluorescent in UV
Reflected-light panel
45.2 %anisotropic · dual curve
Specimen sRGB 233, 166, 95
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Distinct
Reflected colour
White

Crystallography

Crystal system
Orthorhombic
Space group
#73
Cell parameters
a = 22.62 Å · b = 34.08 Å · c = 4.02 Å
Ratio a:b:c
1 : 1.507 : 0.178
Z
4
Morphology

Bladed, fibrous, massive, granular.

Comment

According to Miehe (1971), the Pnnm symmetry of kobellite is disturbed to P21/n for Bi-rich kobellite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth15208.9803134.700
36.44%
82PbLeadLead11207.2002279.200
26.50%
51SbAntimonyAntimony15121.7601826.400
21.23%
16SSulfurSulfur3532.0601122.100
13.05%
29CuCopperCopper263.546127.092
1.48%
26FeIronIron255.845111.690
1.30%
Total8601.182100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ag
  • Fe

In other languages

French
kobellite
German
Kobellit
Spanish
Kobellita
Italian
Kobellite

Classification

Strunz
10th ed.

2.HB.10a

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HBWith Cu, Ag, Fe, Sn and PbGroup
  • 2.HB.10aKobelliteSpecies
Dana
8th ed.

03.06.19.01

  • 03SulfosaltsClass
  • 03.062 < ø < 2.49Type
  • 03.06.19— unnamed intermediate level —Group
  • 03.06.19.01KobelliteSpecies
CIM

5.7.13

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.13KobelliteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1839Setterberg, J. (1839). Undersökning af ett nytt mineral, funnit uti Hvena Kobalt-gruf- vor uti Nerike. Kungliga Vetenskapsacademiens Handlingar för år 1839, p. 188-193. (printing date is given as 1841.) (1840) Jahresberichte Chem. 20: 215.
  2. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  3. 1948Nuffield, E. W. (1948). Observations on kobellite. University of Toronto Studies: VI. Geological Series, 52, 86-89.
  4. 1966Harris, D.C., Jambor, J.L., Lachance, G.R., Thorpe, R.I. (1966). New observations on kobellite. The Canadian Mineralogist, 8, 667-667 (Abs.).
  5. 1968Harris, D. C., Jambor, J. L., Lachance, G. R., Thorpe, R. I. (1968) Tintinaite, the antimony analogue of kobellite. The Canadian Mineralogist, 9 (3) 371-382
