Kupletskite

K2NaMn2+7Ti2(Si4O12)2O2(OH)4F
IMA status
  • Approved
  • Grandfathered
IMA symbol
Kpt
Discovered
1956
Also known as
  • Kupletskiet

Where it forms, where it's found

Geological setting

In natrolite central part of nepheline syenite pegmatites

Type locality
Kuivchorr Mountain
  1. Lovozersky District
  2. Murmansk Oblast
  3. Russia

67.8583°, 34.8755°

33recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark brown to black · brown · yellow

dark brown to black when altered to manganese oxides.

Streak
Brown
Cleavage
Perfect

on [100]

Density
3.20 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 79 – 85° · 2V calc = 78°
Refractive index
1.656 – 1.734
Surface relief
High
Principal indices
nα 1.656 – 1.660 · nβ 1.699 – 1.702 · nγ 1.731 – 1.734
Pleochroism
Visible

Pleochroic with Z brown to X orange-yellow.

Dispersion
relatively weak
Michel-Lévy diagramhighlighted lineδ = 0.0745
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]745 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation745 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.3976 Å · b = 11.9431 Å · c = 11.7092 Å
Cell angles
α = 113.066 ° · β = 94.702 ° · γ = 103.086 °
Ratio a:b:c
1 : 2.213 : 2.169
Z
1
Morphology

Lamellar masses; fine plates; lamellar and acicular crystals

Type-locality form

In lamellar masses up to 5 X 3 X 1 cm, consisting of individual plates with perfect cleavage

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
36.66%
25MnManganeseManganese754.938384.566
29.38%
14SiSiliconSilicon828.085224.680
17.16%
22TiTitaniumTitanium247.86795.734
7.31%
19KPotassiumPotassium239.09878.196
5.97%
11NaSodiumSodium122.99022.990
1.76%
9FFluorineFluorine118.99818.998
1.45%
1HHydrogenHydrogen41.0084.032
0.31%
Total1309.166100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Zr
  • Al
  • Mg
  • Ca
  • Ba
  • H2O

Synonyms

  • Kupletskiet

In other languages

German
Kupletskit
Italian
kupletskite

Classification

Strunz
10th ed.

9.DC.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DCInosilicates with branched 2-periodic single chains; Si2O6 + 2SiO3 Si4O12Group
  • 9.DC.05KupletskiteSpecies
Dana
8th ed.

69.01.01.02

  • 69Inosilicates Chains with Side Branches or LoopsClass
  • 69.01Chains with Side Branches or Loops with (P=2, and N=4, 2 branches)Type
  • 69.01.01Astrophyllite groupGroup
  • 69.01.01.02KupletskiteSpecies
CIM

14.9.28

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.28KupletskiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. Scientia Sinica: 13(7): 1180-1183 (abstract in Chemical Abstracts: 64: 7460).
  2. 1956Semenov, E.I. (1956) Kupletskite - a new mineral of the astrophyllite group. Doklady Akademii Nauk SSSR: 108: 933-936 (in Russian).
  3. 1957Fleischer, M. (1957) New mineral names. American Mineralogist, 42 (1-2). 117-124
  4. 1998Christiansen, Claes C.; Johnsen, Ole; Ståhl, Kenny (1998) Crystal structure of kupletskite from the Kangerdlugssuaq intrusion, East Greenland. Neues Jahrbuch für Mineralogie - Monatshefte, 1998 (6). 253-264
  5. 2001(2001) Kupletskite. Handbook of Mineralogy. Mineralogical Society of America
