Niobokupletskite

K2NaMn7(Nb,Ti)2(Si4O12)2O2(OH)4(O,F)
IMA status
  • Approved
IMA symbol
Nbk
Also known as
  • IMA1999-032
  • Niobokupletskiet

Where it forms, where it's found

Geological setting

Nepheline syenite pegmatites. Late stage mineral.

Type locality
Poudrette quarry (De-Mix quarry
  1. Demix quarry
  2. Uni-Mix quarry
  3. Carrière Mont Saint-Hilaire
  4. MSH)
  5. Mont Saint-Hilaire
  6. La Vallée-du-Richelieu RCM
  7. Montérégie
  8. Québec
  9. Canada

45.5628°, -73.1417°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Light yellow-brown · silvery brown.
Tenacity
brittle
Cleavage
Perfect

Perfect (001)

Fracture
Irregular/Uneven · Splintery
Density
3.46 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.718 – 1.75
Surface relief
High
Principal indices
nα 1.718 · nβ 1.733 · nγ 1.750
Pleochroism
Visible

X ≈ Y = light orange-yellow; Z = red-brown.

Dispersion
r > v strong
Extinction
Z = c; X and Y in the (001) plane.
Notes

γ calculated.

Michel-Lévy diagramhighlighted lineδ = 0.0320
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]320 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation320 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 5.4303 Å · b = 11.924 Å · c = 11.747 Å
Cell angles
α = 112.927 ° · β = 94.750 ° · γ = 103.175 °
Ratio a:b:c
1 : 2.196 : 2.163
Unit cell volume
669.5 ų
Morphology

Three types described from type description: Type-I = anhedral to subhedral, platy to tabular, light beige to yellow epitaxic overgrowths on primary, dark brown kupletskite. Type-II = as a dense, fibrous, light yellow-brown overgrowth on coarse-grained primary kupletskite. Type-III = as an overgrowth on primary kupletskite as very fine-grained bronze to silvery brown acicular crystals in sheaf-like aggregates, originally described as “witch’s broom astrophyllite”.

Type-locality form

Anhedral to subhedral, platy to tabular, light beige to yellow epitaxic overgrowths on primary, dark brown kupletskite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3115.999495.969
32.82%
25MnManganeseManganese754.938384.566
25.45%
14SiSiliconSilicon828.085224.680
14.87%
41NbNiobiumNiobium292.906185.812
12.30%
22TiTitaniumTitanium247.86795.734
6.34%
19KPotassiumPotassium239.09878.196
5.17%
11NaSodiumSodium122.99022.990
1.52%
9FFluorineFluorine118.99818.998
1.26%
1HHydrogenHydrogen41.0084.032
0.27%
Total1510.977100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1999-032
  • Niobokupletskiet

In other languages

German
IMA 1999-032 · Niobokupletskit
Italian
Niobokupletskite

Classification

Strunz
10th ed.

9.DC.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DCInosilicates with branched 2-periodic single chains; Si2O6 + 2SiO3 Si4O12Group
  • 9.DC.05NiobokupletskiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 2000Piilonen, P. C., Lalonde, A. E., McDonald, A. M., Gault, R. A. (2000) Niobokupletskite, a new astrophyllite-group mineral from Mont Saint-Hilaire, Quebec, Canada: Description and crystal structure. The Canadian Mineralogist, 38 (3) 627-639 doi:10.2113/gscanmin.38.3.627 DOI: 10.2113/gscanmin.38.3.627
  2. 2001Jambor, J.L. and Roberts, A.C. (2001) New mineral names. American Mineralogist: 86: 197-200.
  3. 2017Sokolova, Elena, Cámara, Fernando, Hawthorne, Frank C., Ciriotti, Marco E. (2017) The astrophyllite supergroup: nomenclature and classification. Mineralogical Magazine, 81 (1) 143-153 doi:10.1180/minmag.2016.080.077DOI: 10.1180/minmag.2016.080.077
  4. 2021(2021) Niobokupletskite. Handbook of Mineralogy. Mineralogical Society of America
