Labuntsovite-Fe

Na4K4Fe2+2Ti8O4(Si4O12)4(OH)4 · 10-12H2O
IMA status
  • Approved
IMA symbol
Lab-Fe
IMA approved
1998
Also known as
  • IMA1998-051
  • IMA1998-051a
  • Labuntsoviet-Fe

Where it forms, where it's found

Type locality
Kirovskii apatite mine
  1. Kukisvumchorr Mt
  2. Murmansk Oblast
  3. Russia

67.6667°, 33.7167°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Orange
Streak
White
Density
2.94 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 32°
Refractive index
1.686 – 1.835
Surface relief
High
Principal indices
nα 1.686 · nβ 1.696 · nγ 1.835
Pleochroism
Visible

X = Z = pale yellow, Y = orange.

Michel-Lévy diagramhighlighted lineδ = 0.1490
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1490 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1490 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 14.249(6) Å · b = 13.791(6) Å · c = 7.777(2) Å
Cell angles
β = 116.82(3) °
Ratio a:b:c
1 : 0.968 : 0.546
Z
1
Type-locality form

anhedral grains to 2 mm; in aggregates to 0.5 cm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6615.9991055.934
46.47%
14SiSiliconSilicon1628.085449.360
19.77%
22TiTitaniumTitanium847.867382.936
16.85%
19KPotassiumPotassium439.098156.392
6.88%
26FeIronIron255.845111.690
4.92%
11NaSodiumSodium422.99091.960
4.05%
1HHydrogenHydrogen241.00824.192
1.06%
Total2272.464100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • Mn

Synonyms

  • IMA1998-051
  • IMA1998-051a
  • Labuntsoviet-Fe

In other languages

German
IMA 1998-051a · Labuntsovit-Fe
Italian
labuntsovite-Fe

Classification

Strunz
10th ed.

9.CE.30e

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.30eLabuntsovite-FeSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2001Khomyakov, A. P., Nechelyustov, G. N., Ferraris, G., Gula, A., Ivaldi, G. (2001) Labuntsovite-Fe, Na4K4(Ba,K)2(Fe,Mg,Mn)1+xTi8(Si4O12)4(O,OH)8·10H2O and labuntsovite-Mg, Na4K4(Ba,K)2(Mg,Fe)1+xTi8(Si4O12)4(O,OH)8·10H2O - two new minerals from the Khibina and Kovdor alkaline massifs, Kola Peninsula. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 130 (4) 36-45
  2. 2002Chukanov, Nikita V., Pekov, Igor V., Khomyakov, Alexander P. (2002) Recommended nomenclature for labuntsovite-group minerals. European Journal of Mineralogy, 14 (1) 165-173 doi:10.1127/0935-1221/2002/0014-0165 DOI: 10.1127/0935-1221/2002/0014-0165
  3. 2003CHUKANOV, N.V., PEKOV, I.V., ZADOV, A.E., VOLOSHIN, A.V., SUBBOTIN, V.V., SOROKHTINA, N.V., RASTVETAEVA, R.K. & KRIVOVICHEV, S.V. (2003): Minerals of the labuntsovite group. Nauka, Moscow, 323 p. (in Russian).
  4. 2021(2021) Labuntsovite-Fe. Handbook of Mineralogy. Mineralogical Society of America
