Labuntsovite-Mn

Na4K4Mn2+2Ti8O4(Si4O12)4(OH)4 · 10-12H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lab-Mn
Discovered
1925
Also known as
  • Labuntsoviet-Mn
  • Labuntsovite (of Semenov and Burova)
  • Titan-elpidite
  • +1 more

Where it forms, where it's found

Geological setting

In voids in nepheline syenite.

Type locality
Pegmatite No. 19
  1. Kuftnyun Mountain
  2. Lovozersky District
  3. Murmansk Oblast
  4. Russia
14recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Brownish-yellow · bright orange · dark-red
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (100).

Fracture
Sub-Conchoidal
Density
2.89 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 20 – 44° · 2V calc = 30 – 36°
Refractive index
1.684 – 1.814
Surface relief
High
Principal indices
nα 1.684 – 1.695 · nβ 1.693 – 1.702 · nγ 1.792 – 1.814
Pleochroism
Visible

Z = brownish-yellow; X = yellowish.

Dispersion
strong
Extinction
X = b; Y = c; Z = a.
Michel-Lévy diagramhighlighted lineδ = 0.1135
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1135 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1135 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#11
Cell parameters
a = 14.18 Å · b = 13.70 Å · c = 7.74 Å
Cell angles
β = 117 °
Ratio a:b:c
1 : 0.966 : 0.546
Z
1
Morphology

Prismatic crystals. Forms include c(001), b(010), m(110), d(011), and s(111).

Type-locality form

Columnar aggregates of brownish-yellow crystals. The crystals are prismatic to 12x3x2 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6615.9991055.934
46.50%
14SiSiliconSilicon1628.085449.360
19.79%
22TiTitaniumTitanium847.867382.936
16.86%
19KPotassiumPotassium439.098156.392
6.89%
25MnManganeseManganese254.938109.876
4.84%
11NaSodiumSodium422.99091.960
4.05%
1HHydrogenHydrogen241.00824.192
1.07%
Total2270.650100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mn
  • Mg
  • Ca

Synonyms

  • Labuntsoviet-Mn
  • Labuntsovite (of Semenov and Burova)
  • Titan-elpidite
  • Unnamed (MSH UK-5)

In other languages

German
Labuntsovit-Mn
Italian
labuntsovite-Mn

Classification

Strunz
10th ed.

9.CE.30e

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.30eLabuntsovite-MnSpecies
CIM

16.14.8

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.14Aluminosilicates of Ti, Zr, Sn and PbGroup
  • 16.14.8Labuntsovite-MnSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1926Labuntsov, A. (1926) Titaniferous elpidite from Mount Chibina, Russian Lapland, and its paragenesis. Comptes rendus de l'Académie des sciences de l'URSS, 39-42.
  2. 1927Foshag, W.F. (1927) New Mineral Names. American Mineralogist, 12 (7). 295-296
  3. 1955Semenov, E.I. and Burova, T.A. (1955) On the new mineral, labuntsovite, and the so-called titanoelpidite. Doklady Akademii Nauk SSSR, 101, 1113-1116 (in Russian).
  4. 1956Fleischer, M. (1956) New mineral names. American Mineralogist, 41 (1-2). 163-168
  5. 1998Golovina, N.I., Shilov, G.V., Chukanov, N.V., and Pekov, I.V. (1998) Crystal structure of the manganese-rich analog of labuntsovite. Doklady Akademii Nauk: 362(3): 350–352 (in Russian).
