Labuntsovite-Mg

Na4K4Mg2Ti8O4(Si4O12)4(OH)4 · 10-12H2O
IMA status
  • Approved
IMA symbol
Lab-Mg
IMA approved
1998
Also known as
  • IMA1998-050
  • IMA1998-050a
  • IMA2000-A
  • +1 more

Where it forms, where it's found

Type locality
Kovdor Zheleznyi Mine
  1. Kovdor Massif
  2. Kovdorsky District
  3. Murmansk Oblast
  4. Russia

67.5597°, 30.4258°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless to white · rarely yellowish · pink · or light orange
Cleavage
Imperfect/Fair

Imperfect on (001)

Fracture
Step-Like
Density
2.88 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 37°
Refractive index
1.688 – 1.802
Surface relief
High
Principal indices
nα 1.688 · nβ 1.698 · nγ 1.802
Pleochroism
Visible

Pleochroism: X = Z = pale yellow, Y = orange. Colorless varieties nonpleochroic.

Michel-Lévy diagramhighlighted lineδ = 0.1140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1140 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1140 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 14.292(4) Å · b = 13.750(4) Å · c = 7.792(2) Å
Cell angles
β = 117.03(1) °
Ratio a:b:c
1 : 0.962 : 0.545
Z
1
Type-locality form

prismatic crystals to 3 mm

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6615.9991055.934
47.79%
14SiSiliconSilicon1628.085449.360
20.34%
22TiTitaniumTitanium847.867382.936
17.33%
19KPotassiumPotassium439.098156.392
7.08%
11NaSodiumSodium422.99091.960
4.16%
12MgMagnesiumMagnesium224.30548.610
2.20%
1HHydrogenHydrogen241.00824.192
1.10%
Total2209.384100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe

Synonyms

  • IMA1998-050
  • IMA1998-050a
  • IMA2000-A
  • Labuntsoviet-Mg

In other languages

German
IMA 1998-050a · Labuntsovit-Mg
Italian
labuntsovite-Mg

Classification

Strunz
10th ed.

9.CE.30e

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.30eLabuntsovite-MgSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2001Khomyakov, A. P., Nechelyustov, G. N., Ferraris, G., Gula, A., Ivaldi, G. (2001) Labuntsovite-Fe, Na4K4(Ba,K)2(Fe,Mg,Mn)1+xTi8(Si4O12)4(O,OH)8·10H2O and labuntsovite-Mg, Na4K4(Ba,K)2(Mg,Fe)1+xTi8(Si4O12)4(O,OH)8·10H2O - two new minerals from the Khibina and Kovdor alkaline massifs, Kola Peninsula. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 130 (4) 36-45
  2. 2002Chukanov, Nikita V., Pekov, Igor V., Khomyakov, Alexander P. (2002) Recommended nomenclature for labuntsovite-group minerals. European Journal of Mineralogy, 14 (1) 165-173 doi:10.1127/0935-1221/2002/0014-0165 DOI: 10.1127/0935-1221/2002/0014-0165
  3. 2021(2021) Labuntsovite-Mg. Handbook of Mineralogy. Mineralogical Society of America
