Lammerite

Cu3(AsO4)2
IMA status
  • Approved
IMA symbol
Lmr
Discovered
1981
Also known as
  • IMA1980-016
  • Lammeriet

Where it forms, where it's found

Type locality
Laurani Mine
  1. Sica Sica Municipality
  2. Aroma Province
  3. La Paz
  4. Bolivia

-17.3808°, -67.7750°

11recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Dark green
Streak
Pale green
Cleavage
Distinct/Good

good cleavage on (010),and poorer cleavage on (100) and possibly (001)

Density
4.9 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 54° · 2V calc = 50°
Refractive index
1.89 – 2.14
Surface relief
Very high
Principal indices
nα 1.89 · nβ 1.90 – 2.06 · nγ 1.95 – 2.14
Pleochroism
Strong

X = light blue, Y = sky blue, Z = pale bluish green

Dispersion
r > v extreme
Michel-Lévy diagramhighlighted lineδ = 0.1550
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1550 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1550 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 5.079(1) Å · b = 11.611(2) Å · c = 5.394(1) Å
Cell angles
β = 111.72(2) °
Ratio a:b:c
1 : 2.286 : 1.062
Z
2
Type-locality form

Dark green spheroidal aggregates approx. 0.5 cm in diameter on corroded quartzose rock

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper363.546190.638
40.69%
33AsArsenicArsenic274.922149.844
31.99%
8OOxygenOxygen815.999127.992
27.32%
Total468.474100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1980-016
  • Lammeriet

In other languages

German
IMA 1980-016 · Lammerit
Italian
Lammerite

Classification

Strunz
10th ed.

8.AB.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ABWith medium-sized cationsGroup
  • 8.AB.30LammeriteSpecies
Dana
8th ed.

38.03.08.01

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.03(AB)3(XO4)2Type
  • 38.03.08— unnamed intermediate level —Group
  • 38.03.08.01LammeriteSpecies
CIM

20.1.1

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.1Arsenates of CuGroup
  • 20.1.1LammeriteSpecies

Group, growth & confusion

Often grow together
2 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1981Keller, P., Paar, W.H., Dunn, P.J. (1981) Lammerit, Cu3[AsO4]2, ein neues Mineral von Laurani, Bolivien. Tschermaks Mineralogische und Petrographische Mitteilungen: 28: 157-164.
  2. 1982Fleischer, M., Burns, R.G., Cabri, L.J., Francis, C.A., Pabst, A. (1982) New mineral names. American Mineralogist, 67, 413-418.
  3. 1984Filatov, S.K., Gaidamako, L.M., Glavatskikh, S.F., Starova, G.L., Sorokin, N.D. (1984) Exhalation lammerite Cu3[(As,P)O4]2,(Kamchatka). Doklady Akad. Nauk SSSR: 279: 197-200. (in Russian)
  4. 1986Hawthorne, F.C., Dunn, P.J., Grice, J.D., Puziewicz, J., Shigley, J.E. (1986) New mineral names. American Mineralogist: 71: 845-847.
  5. 1986Hawthorne, F.C. (1986) Lammerite, Cu3(AsO4)2, a modulated close-packed structure. American Mineralogist: 71(1-2): 206-209. http://www.minsocam.org/ammin/AM71/AM71_206.pdf
