Lanarkite

Pb2O(SO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lan
Discovered
1832
Also known as
  • Bleisulfocarbonate
  • Dioxylith
  • Halbvitriolblei
  • +5 more

Where it forms, where it's found

Geological setting

A secondary mineral of lead deposits, typically formed by the alteration of galena or other secondary minerals formed from galena.

Type locality
Susanna Mine (Glennery Scar vein
  1. Susanna vein [Scar vein]
  2. Portobello vein
  3. Humby vein
  4. Lead vein)
  5. Leadhills
  6. South Lanarkshire
  7. Scotland
  8. UK

55.4233°, -3.7675°

110recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Greenish white · greyish-white · more rarely pale-yellow · colourless · colourless in transmitted light.
Streak
White
Tenacity
flexible
Cleavage
Perfect

Perfect on (201), imperfect on (402) and (201); also on (010).

Fracture
Splintery
Density
6.92 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60°
Refractive index
1.928 – 2.036
Surface relief
Very high
Principal indices
nα 1.928 · nβ 2.007 · nγ 2.036
Dispersion
r > v strong
UV response
Yellow (LW UV; X-rays).
Michel-Lévy diagramhighlighted lineδ = 0.1080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1080 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1080 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 13.769 Å · b = 5.698 Å · c = 7.079 Å
Cell angles
β = 115.79 °
Ratio a:b:c
1 : 0.414 : 0.514
Z
4
Morphology

Crystals prismatic, elongated parallel to [010], typically microscopic and in clusters or sprays; massive.

Twinning

Polysynthetic in zone [010], but rare.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
78.72%
8OOxygenOxygen515.99979.995
15.19%
16SSulfurSulfur132.06032.060
6.09%
Total526.455100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bleisulfocarbonate
  • Dioxylith
  • Halbvitriolblei
  • Kohlenvitriol-bleispath
  • Lead sulphato-carbonate
  • Plomb sulfatocarbonaté
  • Prismatisches schwefelkohlensaures Blei
  • Sulphato-carbonate of Lead

In other languages

French
lanarkite
German
Lanarkit
Spanish
lanarkita
Italian
lanarkite
Japanese
ラナーカイト · ラナルカイト
Chinese
黃鉛礦

Classification

Strunz
10th ed.

7.BD.40

  • 7SulfatesClass
  • 7.BSulfates (selenates, etc.) with additional anions, without H2ODivision
  • 7.BDWith only large cationsGroup
  • 7.BD.40LanarkiteSpecies
Dana
8th ed.

30.02.01.01

  • 30Anhydrous Sulfates Containing Hydroxyl or HalogenClass
  • 30.02(AB)2(XO4)ZqType
  • 30.02.01— unnamed intermediate level —Group
  • 30.02.01.01LanarkiteSpecies
CIM

25.7.4

  • 25SulphatesClass
  • 25.7Sulphates of PbGroup
  • 25.7.4LanarkiteSpecies

Group, growth & confusion

Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1820Brooke (1820) Edinburgh N. Phil. Journal: 3: 117 (as Sulphato-carbonate of Lead)
  2. 1826Leonhard, K.C. (1826) Handbuch der Oryktognosie. second edition, Heidelberg: 253 (as Prismatisches schwefelkohlensaures Blei).
  3. 1832Beudant, François-Sulpice (1832) Traité élémentaire de minéralogie. Deuxiéme Edition [Elementary Treatise on Mineralogy. Second Edition] (2nd ed.) Vol. 2 - Tome II [Volume II]. Chez Verdière.
  4. 1841Breithaupt, A. (1841) Vollständige Handbuch der Mineralogie. Vol. 2: 180 (as Dioxylith).
  5. 1856Dufrénoy, A. (1856) 3: 255 (as Plomb sulfatocarbonaté).
