Lansfordite

Mg(CO3) · 5H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lfd
Discovered
1888

Where it forms, where it's found

Geological setting

Anthracite coal mine underground workings.

Type locality
Nesquehoning Coal Mine
  1. Nesquehoning
  2. Carbon County
  3. Pennsylvania
  4. USA

40.8625°, -75.8125°

22recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Colourless (fresh) · white (exposed) · colourless in transmitted light.
Streak
White
Cleavage
Perfect

On (001), on (100) less perfect.

Density
1.6 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.465 – 1.507
Surface relief
Low
Principal indices
nα 1.465 · nβ 1.468 · nγ 1.507
Dispersion
r > v strong
Extinction
X = b; Z = c; Y ⊥ {100}.
Michel-Lévy diagramhighlighted lineδ = 0.0420
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]420 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation420 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 7.3458 Å · b = 7.6232 Å · c = 12.4737 Å
Cell angles
β = 101.722 °
Ratio a:b:c
1 : 1.038 : 1.698
Unit cell volume
683.81 ų
Z
4
Morphology

Minute short-prismatic crystals [001]; also stalactitic.

Type-locality form

Small stalactites attached to carbonaceous shale.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
73.39%
12MgMagnesiumMagnesium124.30524.305
13.94%
6CCarbonCarbon112.01112.011
6.89%
1HHydrogenHydrogen101.00810.080
5.78%
Total174.388100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

French
lansfordite
German
Lansfordit
Italian
Lansfordite

Classification

Strunz
10th ed.

5.CA.10

  • 5CarbonatesClass
  • 5.CCarbonates without additional anions, with H2ODivision
  • 5.CAWith medium-sized cationsGroup
  • 5.CA.10LansforditeSpecies
Dana
8th ed.

15.01.06.01

  • 15Hydrated Normal CarbonatesClass
  • 15.01A(XO3)·xH2OType
  • 15.01.06— unnamed intermediate level —Group
  • 15.01.06.01LansforditeSpecies
CIM

11.3.4

  • 11CarbonatesClass
  • 11.3Carbonates of MgGroup
  • 11.3.4LansforditeSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1888Genth, F.A. (1888) Lansfordit, ein neues mineral. Zeitschrift für Krystallographie und Mineralogie: 14: 255-256.
  2. 1890Genth, F.A., Penfield, S.L. (1890) On lansfordite, nesquehonite, a new mineral, and pseudomorphs of nesquehonite after lansfordite. American Journal of Science: 39: 121-137.
  3. 1910Cesàro (1910) Académie royale des sciences de Belgique, Cl. sc., Bull., Brussels: 4: 234.
  4. 1910Leitmeier (1910) Zeitschrift für Kristallographie, Mineralogie und Petrographie: 47: 104.
  5. 1924Poitevin, Eugene (1924) A new occurrence of lansfordite from Atlin, B. C. American Mineralogist, 9 (11) 225-227
