Hydromagnesite

Mg5(CO3)4(OH)2 · 4H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hmgs
Discovered
1827
Also known as
  • Hydrocarbonate of Magnesia
  • Hydromagnesita
  • Hydromagnesite (of Wachmeister)
  • +5 more

Where it forms, where it's found

Geological setting

Low-temperature, hydrothermal environments in serpentine and altered magnesium-rich igneous rocks.

Type locality
Castle Point
  1. Hoboken
  2. Hudson County
  3. New Jersey
  4. USA

40.7450°, -74.0233°

292recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless to white · colourless in transmitted light
Tenacity
brittle
Cleavage
Perfect

On (010).

Density
2.24 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 50° · 2V calc = 52°
Refractive index
1.523 – 1.545
Surface relief
Moderate
Principal indices
nα 1.523 · nβ 1.527 · nγ 1.545
Birefringence
0.022
Dispersion
none
UV response
Sometimes fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]220 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation220 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 10.105(5) Å · b = 8.954(2) Å · c = 8.378(4) Å
Cell angles
β = 114.44(5) °
Ratio a:b:c
1 : 0.886 : 0.829
Z
2
Morphology

Crystals small, occurring as tufts, rosettes, or crusts of acicular or bladed crysta;s elongated [001] and flattened (100). Massive, chalky.

Twinning

Twin plane (100) and composition face (100). Twinning very common, polysynthetic.

Parting
Possible parting on (100).
Comment

pseudo-orthorhombic.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
61.58%
12MgMagnesiumMagnesium524.305121.525
25.99%
6CCarbonCarbon412.01148.044
10.27%
1HHydrogenHydrogen101.00810.080
2.16%
Total467.631100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hydrocarbonate of Magnesia
  • Hydromagnesita
  • Hydromagnesite (of Wachmeister)
  • Hydromagnocalcite
  • Idromagnesit
  • Idromagnesita
  • Lancasterit
  • Lancasterita

In other languages

French
Hydromagnésite
German
Hydromagnesit
Spanish
Hidromagnesita
Italian
Idromagnesite
Japanese
水苦土石
Chinese
水菱镁石

Classification

Strunz
10th ed.

5.DA.05

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DAWith medium-sized cationsGroup
  • 5.DA.05HydromagnesiteSpecies
Dana
8th ed.

16b.07.01.01

  • 16bHydrated Carbonates Containing Hydroxyl or HalogenClass
  • 16b.07MiscellaneousType
  • 16b.07.01— unnamed intermediate level —Group
  • 16b.07.01.01HydromagnesiteSpecies
CIM

11.3.7

  • 11CarbonatesClass
  • 11.3Carbonates of MgGroup
  • 11.3.7HydromagnesiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1827Trolle-Wachmeister, Hans Gabriel (1827) Svenska Vetenskapsakademien, Stockholm, Handlingar: 18.
  2. 1828Wachtmeister, T. (1828) Analys af ett pulverformigt mineral från Norra Amerika. Kongliga Svenska Vetenskaps-Akademiens Handlingar: 1828: 17-19.
  3. 1835von Kobell, Wolfgang Xavier Franz (1835) Ueber den Hydromagnesit von Kumi auf Negroponte. Journal für praktische Chemie, Leipzig: 4: 80-81.
  4. 1850Silliman Jr., Benjamin (1850) [Lancasterite]. American Journal of Science: 9: 216 (as Lancasterite).
  5. 1897Weinschenk (1897) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 27: 570.
