Where it forms, where it's found
- Geological setting
high-pressure, low-temperature metamorphism
- Type locality
- Vanoise
- Savoie
- Auvergne-Rhône-Alpes
- France
45.4053°, 6.8275°
15recorded occurrences
Physical
- Hardness
- 1Talc
- 2Gypsum
- 3Calcite
- 4Fluorite
- 5Apatite
- 6Orthoclase
- 7Quartz
- 8Topaz
- 9Corundum
- 10Diamond
- Transparency
- Transparent
- Colour
- Light green to grayish
- Density
- 2.88 g/cm³
Optical
- Optical type
- Biaxial (-) · 2V measured = 50 – 60° · 2V calc = 88°
- Refractive index
- 1.59 – 1.61
- Surface relief
- Moderate
- Principal indices
- nα 1.59 · nβ 1.6 · nγ 1.61
- Dispersion
- r > v distinct
Δ = 0Δmax
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour
Crystallography
- Space group
- Ccca
- Cell parameters
- a = 13.714(2) Å · b = 20.079(2) Å · c = 5.105(1) Å
- Ratio a:b:c
- 1 : 1.464 : 0.372
- Z
- 8
- Morphology
small acicular to fibrous crystals
Crystal structure
Chemical composition
- Impurities
- Ti
- Fe
- Mn
- Ca
- Na
- K
- H2O
- P
Synonyms
- IMA1978-027
- Magnesiocarpholiet
- Magnesiocarpholit
In other languages
- German
- IMA 1978-027 · Magnesiokarpholith
- Italian
- Magnesiocarfolite · Magnesiocarpholite
Classification
Strunz
10th ed.9.DB.05
- 9SilicatesClass
- 9.DInosilicatesDivision
- 9.DBInosilicates with 2-periodic single chains, Si2O6; Pyroxene-related mineralsGroup
- 9.DB.05MagnesiocarpholiteSpecies
Dana
8th ed.65.01.05.03
- 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
- 65.01Single-Width Unbranched Chains, W=1 with chains P=2Type
- 65.01.05Carpholite groupGroup
- 65.01.05.03MagnesiocarpholiteSpecies
CIM
—16.19.12
- 16Silicates Containing Aluminum and other MetalsClass
- 16.19Aluminosilicates of Fe and MgGroup
- 16.19.12MagnesiocarpholiteSpecies
Group, growth & confusion
Literature, links & citation
Citations
- 1973Goffé, B., Goffé-Urbano, G., Saliot, P. (1973) Sur la présence d'une variété magnésienne de ferrocarpholite en Vanoise (Alpes françaises). Comptes Rendus de l'Académie des Sciences de Paris, 277, 1965-1968.
- 1979Viswanathan, K., Seidel, E. (1979) Crystal chemistry of Fe-Mg-carpholites. Contributions to Mineralogy and Petrology, 70 (1) 41-47 doi:10.1007/bf00371870DOI: 10.1007/bf00371870
- 1980Goffé, B. (1980) Magnésiocarpholite, cookéite et euclase dans les niveaux continentaux métamorphiques de la zone briançonnaise. Données minéralogiques et nouvelles occurrences. Bulletin de la Société française de Minéralogie et de Cristallographie: 103: 297-302.
- 1981Viswanathan, Krishnamoorthy (1981) The crystal structure of a Mg-rich carpholite. American Mineralogist, 66 (9-10) 1080-1085
- 1981Chopin, Christian, Goffé, Bruno (1981) High-pressure synthesis and properties of magnesiocarpholite, MgAl2[Si2O6] (OH)4. Contributions to Mineralogy and Petrology, 76 (3). 260-264 doi:10.1007/bf00375453DOI: 10.1007/bf00375453
