Mampsisite

Ca4Al2(CO3)(OH)12·5H2O
IMA status
  • Approved
IMA symbol
Mmp
Also known as
  • Mampsisiet

Where it forms, where it's found

Geological setting

Mampsisite was discovered in peralkaline hydrothermal assemblages confined to pyrometamorphic rocks of the Hatrurim Basin in the Negev desert, nearby the Israeli coast of the Dead Sea. The mineral occurs in the cavities of marble-like larnite-brownmillerite-jasmundite rock. The assemblage was formed from residual highly alkaline solutions produced by late hydrothermal alteration of larnite, Ca2SiO4, and jasmundite, Ca11(SiO4)4O2S.

Type locality
Amoraite type locality
  1. Hatrurim Basin
  2. Tamar Regional Council
  3. Beersheba Subdistrict
  4. Southern District
  5. Israel

31.2083°, 35.2583°

1recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
colorless
Tenacity
brittle
Cleavage
Perfect

(001)

Density
2.180 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 25°
Refractive index
1.535 – 1.551
Surface relief
Moderate
Principal indices
nα 1.535 · nβ 1.551 · nγ 1.551
Pleochroism
Non-pleochroic
Notes

β(calc)

Michel-Lévy diagramhighlighted lineδ = 0.0160
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]160 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation160 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.7834(2) Å · b = 9.9274(3) Å · c = 15.0972(4) Å
Cell angles
α = 87.198(2) ° · β = 89.805(2) ° · γ = 89.967(2) °
Ratio a:b:c
1 : 1.717 : 2.610
Z
2
Type-locality form

platy crystals up to 50 μm across

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
56.29%
20CaCalciumCalcium440.078160.312
28.20%
13AlAluminiumAluminium226.98253.964
9.50%
1HHydrogenHydrogen221.00822.176
3.90%
6CCarbonCarbon112.01112.011
2.11%
Total568.443100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • Mampsisiet

In other languages

German
Mampsisit
Italian
Mampsisite

Classification

Strunz
10th ed.

4.FL.100

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FLHydroxides with H2O +- (OH); sheets of edge-sharing octahedraGroup
  • 4.FL.100MampsisiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 2024Bosi, Ferdinando, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2024) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 77. European Journal of Mineralogy, 36 (1). 165-172 doi:10.5194/ejm-36-165-2024DOI: 10.5194/ejm-36-165-2024
  2. 2026Britvin, Sergey N.; Murashko, Mikhail N.; Vlasenko, Natalia S.; Vereshchagin, Oleg S.; Bocharov, Vladimir N.; Vapnik, Yevgeny (2026) Mampsisite, Ca4Al2(OH)12(CO3)·5H2O, a new mineral and a new polymorph of the cementitious AFm monocarboaluminate. American Mineralogist, 111 (5). p.826-835. doi:10.2138/am-2025-9950DOI: 10.2138/am-2025-9950
