Mangani-dellaventuraite

NaNa2(MgMn3+2Ti4+Li)Si8O22O2
IMA status
  • Approved
IMA symbol
Mdv
IMA approved
2003
Also known as
  • Dellaventuraite
  • IMA2003-061
  • Mangani-dellaventuraiet

Where it forms, where it's found

Geological setting

Metamorphosed manganese ores.

Type locality
Kajlidongri Mine
  1. Jhabua District
  2. Madhya Pradesh
  3. India

22.9457°, 74.4682°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Pink to red
Streak
Pale pink
Tenacity
brittle
Cleavage
Perfect

(110). Cleavage intersecting at ~56°.

Fracture
Conchoidal
Density
3.184 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 46 – 52° · 2V calc = 41°
Refractive index
1.685 – 1.724
Surface relief
High
Principal indices
nα 1.685 – 1.691 · nβ 1.687 – 1.697 · nγ 1.718 – 1.724
Pleochroism
Strong

X = pale mauve-brown; Y ~ Z = dark red-brown.

Extinction
Y ∧ a = 20° (in β obtuse); Z = b.
UV response
Not fluorescent.
Notes

Absorption: X < Y ~ Z.

Michel-Lévy diagramhighlighted lineδ = 0.0330
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]330 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation330 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.808 Å · b = 17.84 Å · c = 5.2848 Å
Cell angles
α = 104.653 °
Ratio a:b:c
1 : 1.819 : 0.539
Unit cell volume
894.6 ų
Z
2
Morphology

Anhedral grains.

Type-locality form

Pink to red, anhedral to subhedral crystals with an average grain size of 0.4 mm and a maximum size of 1.5 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
44.31%
14SiSiliconSilicon828.085224.680
25.93%
25MnManganeseManganese254.938109.876
12.68%
11NaSodiumSodium322.99068.970
7.96%
22TiTitaniumTitanium147.86747.867
5.52%
12MgMagnesiumMagnesium124.30524.305
2.80%
3LiLithiumLithium16.9406.940
0.80%
Total866.614100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Dellaventuraite
  • IMA2003-061
  • Mangani-dellaventuraiet

In other languages

German
IMA 2003-061 · Mangani-Dellaventurait
Italian
dellaventuraite · mangani-dellaventuraite

Classification

Strunz
10th ed.

9.DE.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.25Mangani-dellaventuraiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 2005Tait, Kimberly T., Hawthorne, Frank C., Grice, Joel D., Ottolini, Luisa, Nayak, V. K. (2005) Dellaventuraite, NaNa2(MgMn3+2Ti4+Li)Si8O22O2, a new anhydrous amphibole from the Kajlidongri Manganese Mine, Jhabua District, Madhya Pradesh, India. American Mineralogist, 90 (2-3) 304-309
  2. 2012Hawthorne, F. C., Oberti, R., Harlow, G. E., Maresch, W. V., Martin, R. F., Schumacher, J. C., Welch, M. D. (2012) Nomenclature of the amphibole supergroup. American Mineralogist, 97 (11) 2031-2048 doi:10.2138/am.2012.4276 DOI: 10.2138/am.2012.4276
