Mangano-mangani-ungarettiite

NaNa2(Mn2+2Mn3+3)Si8O22O2
IMA status
  • Approved
IMA symbol
Mmu
Discovered
1995
Also known as
  • IMA1994-004
  • Mangano-mangani-ungarettiiet
  • Ungarettiit
  • +2 more

Where it forms, where it's found

Geological setting

Manganese silicate and oxide rocks.

Type locality
Hoskins mine
  1. Grenfell
  2. Forbes Co.
  3. New South Wales
  4. Australia

-33.8958°, 148.1228°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Cherry red to very dark red
Streak
Pale pinkish white
Cleavage
Perfect

Perfect on (110), characteristic of monoclinic amphiboles, intersecting at ~56°.

Density
3.52 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 57° · 2V calc = 56°
Refractive index
1.717 – 1.8
Surface relief
High
Principal indices
nα 1.717 · nβ 1.78 · nγ 1.8
Pleochroism
Strong

X = orange-red; Y ≈ Z = very dark red.

Dispersion
r < v
Extinction
X ∧ a: -2° (in β acute); Y = b; Z ∧ c : l7° (in β obtuse).
Luminescence
Nonfluorescent
UV response
Not fluorescent.
Notes

Absorption: X < Y <= Z.

Michel-Lévy diagramhighlighted lineδ = 0.0830
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]830 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation830 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.885(5) Å · b = 18.031(6) Å · c = 5.296(2) Å
Cell angles
β = 105.87(6) °
Ratio a:b:c
1 : 1.824 : 0.536
Type-locality form

Lustrous, dark red to brownish red acicular prismatic grains. Also as felted aggregates of elongate grains.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
40.32%
25MnManganeseManganese554.938274.690
28.85%
14SiSiliconSilicon828.085224.680
23.59%
11NaSodiumSodium322.99068.970
7.24%
Total952.316100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mg
  • Ca
  • K
  • Li

Synonyms

  • IMA1994-004
  • Mangano-mangani-ungarettiiet
  • Ungarettiit
  • Ungarettiita
  • Ungarettiite

In other languages

German
IMA 1994-004 · Mangano-Mangani-Ungarettiit
Italian
mangano-mangani-ungarettiite · ungarettiite
Chinese
锰钠闪石

Classification

Strunz
10th ed.

9.DE.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.25Mangano-mangani-ungarettiiteSpecies
Dana
8th ed.

66.01.3c.14

  • 66Inosilicates Double-width, Unbranched Chains, (w=2)Class
  • 66.01Amphiboles - Mg-Fe-Mn-Li subgroupType
  • 66.01.3c— unnamed intermediate level —Group
  • 66.01.3c.14Mangano-mangani-ungarettiiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1995Hawthorne, Frank C., Oberti, Roberta, Cannillo, Elio, Sardone, Nicola, Zanetti, Alberto, Grice, Joel D., Ashley, Paul M. (1995) A new anhydrous amphibole from the Hoskins Mine, Grenfell, New South Wales, Australia; description and crystal structure of ungarettiite, NaNa2(Mn2+2Mn3+3)Si8O22O2. American Mineralogist, 80 (1) 165-172 doi:10.2138/am-1995-1-216 DOI: 10.2138/am-1995-1-216
  2. 1996Mandarino, Joseph A. (1996) Abstracts of New Mineral Descriptions. The Mineralogical Record, 27 (5) 393-395
  3. 1997Leake, Bernard E., Woolley, Alan R., Arps, C.E.S., Birch, W.D., Gilbert, M.C., Grice, J.D., Hawthorne, Ec., Kato, A., Kisch, H.J., Krivovichev, V.G., Linthout, K., Laird, J., Mandarino, J., Maresch, W.V., Nickel, E.H., Rock, N.M.S., Schumacher, J.C., Smith, D.C., Stephenson, N.C.N., Ungaretti, L., Whittaker, E.J.W., Youzhi, G. (1997) Nomenclature of amphiboles Report of the Subcommittee on Amphiboles of the International Mineralogical Association Commission on New Minerals and Mineral Names. European Journal of Mineralogy, 9 (3) 623-651 doi:10.1127/ejm/9/3/0623DOI: 10.1127/ejm/9/3/0623
  4. 1998Mandarino, Joseph A. (1998) The Second List of Additions and Corrections to the Glossary of Mineral Species (1995) - The Amphibole Group. The Mineralogical Record, 29 (3) 169-174
  5. 2002Kawachi, Yosuke, Coombs, Douglas S., Leake, Bernard E., Hinton, Richard W. (2002) The anhydrous amphibole ungarettiite from the Woods mine, New South Wales, Australia. European Journal of Mineralogy, 14 (2) 375-377 doi:10.1127/0935-1221/2002/0014-0375DOI: 10.1127/0935-1221/2002/0014-0375
