Manganoneptunite

KNa2LiMn2+2Ti2Si8O24
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mnnpt
Also known as
  • Mangan-neptunite
  • Manganneptunit
  • Manganneptunite
  • +2 more

Where it forms, where it's found

Geological setting

Pegmatite in nepheline syenite.

Type locality
Maly Mannepakhk Mt (Malyi Mannepakhk Mt)
  1. Murmansk Oblast
  2. Russia
28recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Red
Streak
Brick-red, reddish brown.
Tenacity
brittle
Cleavage
Distinct/Good

Distinct in two directions, intersecting at ~80°.

Fracture
Irregular/Uneven · Conchoidal
Density
3.17 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 31 – 36° · 2V calc = 40°
Refractive index
1.691 – 1.728
Surface relief
High
Principal indices
nα 1.691 – 1.697 · nβ 1.693 – 1.700 · nγ 1.713 – 1.728
Pleochroism
Strong

X = light yellow; Y = orange or yellow-orange; Z = red-orange.

Dispersion
r > v strong
Extinction
Y = b; Z ∧ c = 16°-20°.
Notes

Absorption: Z > Y > X.

Michel-Lévy diagramhighlighted lineδ = 0.0265
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]265 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation265 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
Cc
Cell parameters
a = 16.4821(6) Å · b = 12.5195(4) Å · c = 10.0292(3) Å
Cell angles
β = 115.474(1) °
Ratio a:b:c
1 : 0.760 : 0.608
Unit cell volume
1868.31 ų
Morphology

Prismatic crystals, elongated along [001]. Forms include (110), (001), (100). Also (111), (111) and rare (210).

Twinning

Contact twinning on (001).

Type-locality form

Dark cherry-red crystalline granular aggregates, some of significant size and included with aegirine.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
42.37%
14SiSiliconSilicon828.085224.680
24.79%
25MnManganeseManganese254.938109.876
12.12%
22TiTitaniumTitanium247.86795.734
10.56%
11NaSodiumSodium222.99045.980
5.07%
19KPotassiumPotassium139.09839.098
4.32%
3LiLithiumLithium16.9406.940
0.77%
Total906.284100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Mangan-neptunite
  • Manganneptunit
  • Manganneptunite
  • Manganoneptuniet
  • Mn-Neptunite

In other languages

German
Manganoneptunit
Italian
Mangan-neptunite · manganoneptunite

Classification

Strunz
10th ed.

9.EH.05

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EHTransitional structures between phyllosilicate and other silicate unitsGroup
  • 9.EH.05ManganoneptuniteSpecies
Dana
8th ed.

70.04.01.02

  • 70Inosilicates Column or Tube StructuresClass
  • 70.04Column or Tube Structures with linked chains forming cagesType
  • 70.04.01Neptunite groupGroup
  • 70.04.01.02ManganoneptuniteSpecies
CIM

14.9.27

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.27ManganoneptuniteSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1923Kurbatov, S.M. (1923): Analyse d'une neptounite manganifère des Monts Chibines en Laponie russe. Comptes Rendus de l’Académie des Sciences de Russie, 1, 59-60.
  2. 1926Fersman, A. E. (1926) Minerals of the Kola Peninsula. American Mineralogist: 11: 289-299.
  3. 1927Foshag, W.F.; Schairer, J.F. (1927) New Mineral Names. American Mineralogist, 12 (3). 95-98
  4. 1953Bøggild, O. B. (1953) The Mineralogy of Greenland. Meddelelser om Grønland Vol. 149 (3) C.A.Reitzel
  5. 1965Mandarino, J.A., Harris, D.C., Bradley, J. (1965): Mangan neptunite, epididymite, and new species from Mont St. Hilaire. The Canadian Mineralogist, 8, 398. (Abstract)
