Manganosegelerite

Mn2+2Fe3+(PO4)2(OH) · 4H2O
IMA status
  • Approved
IMA symbol
Msgl
Discovered
1984
IMA approved
1984
Also known as
  • IMA1984-055
  • Manganosegeleriet

Where it forms, where it's found

Geological setting

late fractures in granitic pegmatites

Type locality
Vasin-Myl'k Mt
  1. Voron'i Tundry
  2. Murmansk Oblast
  3. Russia

68.3833°, 35.8633°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
yellow or yellow-green
Streak
Pale yellow
Tenacity
brittle
Cleavage
Poor/Indistinct

(001)

Fracture
Irregular/Uneven · Splintery
Density
2.76 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 70 – 75° · 2V calc = 72°
Refractive index
1.657 – 1.691
Surface relief
High
Principal indices
nα 1.657 · nβ 1.668 · nγ 1.691
Birefringence
0.034
Pleochroism
Visible

X yellow Z Light yellow

Dispersion
r < v marked
Michel-Lévy diagramhighlighted lineδ = 0.0340
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]340 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation340 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#61
Cell parameters
a = 14.89 Å · b = 18.79 Å · c = 7.4 Å
Ratio a:b:c
1 : 1.262 : 0.497
Morphology

Slightly elongated tablets.

Type-locality form

fine-grained aggregates (to 2mm across) of poorly devloped prismatic individuals up to 0.05mm across

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1315.999207.987
46.77%
25MnManganeseManganese254.938109.876
24.70%
15PPhosphorusPhosphorus230.97461.948
13.93%
26FeIronIron155.84555.845
12.56%
1HHydrogenHydrogen91.0089.072
2.04%
Total444.728100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al

Synonyms

  • IMA1984-055
  • Manganosegeleriet

In other languages

German
IMA 1984-055 · Manganosegelerit
Italian
Manganosegelerite

Classification

Strunz
10th ed.

8.DH.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DHWith large and medium-sized cations, (OH, etc.):RO4 < 1:1Group
  • 8.DH.20ManganosegeleriteSpecies
Dana
8th ed.

42.11.01.03

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.01Overite GroupGroup
  • 42.11.01.03ManganosegeleriteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1992Voloshin, A.V., Pakhomovskiy, Y.A., Tyusheva, F.N. (1992) Manganosegelerite (Mn,Ca)(Mn,Fe,Mg)Fe3+(PO4)2(OH)·4H2O: a new phosphate of the overite group from granitic pegmatites of the Kola Peninsula. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva: 121(2): 95-103.
  2. 1994Jambor, John L., Grew, Edward S. (1994) New Mineral Names. American Mineralogist, 79 (1-2) 185-189
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  4. 2005(2005) Manganosegelerite. Handbook of Mineralogy. Mineralogical Society of America
