Mendozavilite-KCa

[K2(H2O)15Ca(H2O)6][Mo8P2Fe3+3O34(OH)3]
IMA status
  • Approved
IMA symbol
Mdz-KCa
IMA approved
2011
Also known as
  • IMA2011-088
  • Mendozaviliet-KCa

Where it forms, where it's found

Type locality
Chuquicamata Mine
  1. Chuquicamata District
  2. Calama
  3. El Loa Province
  4. Antofagasta
  5. Chile

-22.2894°, -68.9011°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Greenish yellow
Streak
Very pale yellowish green
Tenacity
brittle
Cleavage
Perfect
Fracture
Irregular/Uneven

Optical

Optical type
Biaxial (+) · 2V measured = 80°
Refractive index
1.78 – 1.817
Surface relief
High
Principal indices
nα 1.780 · nβ 1.795 · nγ 1.817
Pleochroism
Non-pleochroic
Dispersion
r < v, strong
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0370
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]370 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation370 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 18.909(5) Å · b = 10.897(2) Å · c = 14.958(4) Å
Cell angles
β = 129.780(9) °
Ratio a:b:c
1 : 0.576 : 0.791
Unit cell volume
2368.6 ų
Morphology

Pseudeohexagonal, tabular crystals up to 0.5 mm across and 0.05 mm thick. Forms observed: (001),(110),(111),{20-1} and (110)

Twinning

Ubiquitous: Contact on (001) and penetration, both on roatation of 120° about [102].

Parting
(001)
Type-locality form

Greenish yellow pseudohexagonal crystals on massive vein quartz

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen5815.999927.942
44.43%
42MoMolybdenumMolybdenum895.950767.600
36.75%
26FeIronIron355.845167.535
8.02%
19KPotassiumPotassium239.09878.196
3.74%
15PPhosphorusPhosphorus230.97461.948
2.97%
1HHydrogenHydrogen451.00845.360
2.17%
20CaCalciumCalcium140.07840.078
1.92%
Total2088.659100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2011-088
  • Mendozaviliet-KCa

In other languages

German
IMA 2011-088 · Mendozavilit-KCa
Italian
mendozavilite-KCa

Classification

Strunz
10th ed.

7.GB.50

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GBWith additional anions and/or H2OGroup
  • 7.GB.50Mendozavilite-KCaSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 12. Mineralogical Magazine, 76 (1) 151-155 doi:10.1180/minmag.2012.076.1.151 DOI: 10.1180/minmag.2012.076.1.151
  2. 2012Kampf, A. R., Mills, S. J., Rumsey, M. S., Dini, M., Birch, W. D., Spratt, J., Pluth, J. J., Steele, I. M., Jenkins, R. A., Pinch, W. W. (2012) The heteropolymolybdate family: structural relations, nomenclature scheme and new species. Mineralogical Magazine, 76 (5) 1175-1207 doi:10.1180/minmag.2012.076.5.09DOI: 10.1180/minmag.2012.076.5.09
  3. 2021(2021) Mendozavilite-KCa. Handbook of Mineralogy. Mineralogical Society of America
