Mendozavilite-NaCu

[Na2(H2O)15Cu(H2O)6][Mo8P2Fe3+3O34(OH)3]
IMA status
  • Approved
IMA symbol
Mdz-NaCu
IMA approved
2011
Also known as
  • IMA2011-039
  • Mendozaviliet-NaCu

Where it forms, where it's found

Geological setting

In the oxidation zone of a porphyry copper deposit

Type locality
Lomas Bayas Mine
  1. Lomas Bayas mining district
  2. Sierra Gorda
  3. Antofagasta Province
  4. Antofagasta
  5. Chile

-23.4278°, -69.5114°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Lime green
Streak
Colorless to very pale green
Tenacity
flexible
Cleavage
Perfect

(001)

Fracture
Irregular/Uneven
Density
2.824 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80°
Refractive index
1.77 – 1.805
Surface relief
High
Principal indices
nα 1.770 · nβ 1.785 · nγ 1.805
Pleochroism
Visible

Pale olive green, Y > X = Z

Dispersion
r < v, strong, inclined
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0350
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]350 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation350 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 18.9984(16) Å · b = 10.9296(7) Å · c = 15.0818(12) Å
Cell angles
β = 129.906(2) °
Ratio a:b:c
1 : 0.575 : 0.794
Morphology

Sixsided (pseudohexagonal) tabular crystals up to 1 mm across and 0.1mm thick. Forms observed: (001),(110), (111),{20-1} and (110).

Twinning

Ubiquitous: contact on (001) and penetration, both on roatation of 120° about [102].

Parting
(001)
Type-locality form

As thin vein fillings and well developed crystals in cavities of quartz

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen5815.999927.942
44.61%
42MoMolybdenumMolybdenum895.950767.600
36.91%
26FeIronIron355.845167.535
8.05%
29CuCopperCopper163.54663.546
3.06%
15PPhosphorusPhosphorus230.97461.948
2.98%
11NaSodiumSodium222.99045.980
2.21%
1HHydrogenHydrogen451.00845.360
2.18%
Total2079.911100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2011-039
  • Mendozaviliet-NaCu

In other languages

German
IMA 2011-039 · Mendozavilit-NaCu
Italian
mendozavilite-NaCu

Classification

Strunz
10th ed.

7.GB.50

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GBWith additional anions and/or H2OGroup
  • 7.GB.50Mendozavilite-NaCuSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2011, CNMNC Newsletter No. 10. Mineralogical Magazine, 75 (5) 2549-2561 doi:10.1180/minmag.2011.075.5.2549 DOI: 10.1180/minmag.2011.075.5.2549
  2. 2012Kampf, A. R., Mills, S. J., Rumsey, M. S., Dini, M., Birch, W. D., Spratt, J., Pluth, J. J., Steele, I. M., Jenkins, R. A., Pinch, W. W. (2012) The heteropolymolybdate family: structural relations, nomenclature scheme and new species. Mineralogical Magazine, 76 (5) 1175-1207 doi:10.1180/minmag.2012.076.5.09DOI: 10.1180/minmag.2012.076.5.09
  3. 2021(2021) Mendozavilite-NaCu. Handbook of Mineralogy. Mineralogical Society of America
