Natrowalentaite

[Fe3+0.5Na0.5(H2O)6][NaAs3+2(Fe3+2.33W6+0.67)(PO4)2O7]
IMA status
  • Approved
  • Pending publication
IMA symbol
Nwal
IMA approved
2018
Also known as
  • IMA2018-032a
  • Natrowalentaiet

Where it forms, where it's found

Type locality
Griffins Find Gold Mine
  1. Lake Grace Shire
  2. Western Australia
  3. Australia

-33.0698°, 118.3200°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Colour
Greenish-yellow
Cleavage
Perfect

(100)

Density
2.91 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 71°
Refractive index
1.65 – 1.772
Surface relief
High
Principal indices
nα 1.650 · nβ 1.728 · nγ 1.772
Pleochroism
Not Visible
Michel-Lévy diagramhighlighted lineδ = 0.1220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1220 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1220 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Imma
Cell parameters
a = 25.770(3) Å · b = 7.3250(8) Å · c = 10.522(1) Å
Ratio a:b:c
1 : 0.284 : 0.408
Z
4
Type-locality form

aggregates of extremely thin (1 to 3 μm), bright greenish-yellow blades with lengths up to 200 μm, on natropharmacosiderite.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
38.37%
26FeIronIron2.8355.845158.041
18.05%
33AsArsenicArsenic274.922149.844
17.11%
74WTungstenTungsten0.67183.840123.173
14.07%
15PPhosphorusPhosphorus230.97461.948
7.08%
11NaSodiumSodium1.522.99034.485
3.94%
1HHydrogenHydrogen121.00812.096
1.38%
Total875.566100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2018-032a
  • Natrowalentaiet

In other languages

German
Natrowalentait

Classification

Strunz
10th ed.

8.CH.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CHWith large and medium-sized cations, RO4:H2O < 1:1Group
  • 8.CH.05NatrowalentaiteSpecies

Group, growth & confusion

In the same group
1 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1987Nickel, E.H. (1987) Tungsten-bearing walentaite from Griffins Find gold deposit, Western Australia. Australian Mineralogist, 2(1), 9–12.
  2. 2018Hålenius, Ulf, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2018) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) NEWSLETTER 46. European Journal of Mineralogy, 30 (6) 1181-1189 doi:10.1127/ejm/2018/0030-2819DOI: 10.1127/ejm/2018/0030-2819
  3. 2021(2021) Natrowalentaite. Handbook of Mineralogy. Mineralogical Society of America
