Newberyite

Mg(PO3OH) · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
New
Discovered
1879
Also known as
  • Newberyiet

Where it forms, where it's found

Geological setting

Bat guano cave deposit.

Bat guano deposits.

Type locality
Skipton Caves
  1. Mount Widderin
  2. Skipton
  3. Corangamite Shire
  4. Victoria
  5. Australia

-37.7370°, 143.3478°

25recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Light gray to white or colorless · pale brown

Colorless in transmitted light.

Streak
White
Cleavage
Perfect

On (010), perfect; on (001), poor.

Fracture
Hackly
Density
2.10 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 45° · 2V calc = 48°
Refractive index
1.514 – 1.533
Surface relief
Moderate
Principal indices
nα 1.514 · nβ 1.518 · nγ 1.533
Birefringence
0.019
Pleochroism
Non-pleochroic
Dispersion
relatively weak, r < v, perceptible.
Extinction
X = a; Y = b; Z = c.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pbca
Cell parameters
a = 10.203 Å · b = 10.685 Å · c = 10.018 Å
Ratio a:b:c
1 : 1.047 : 0.982
Z
16
Morphology

Crystals equi-dimentional, short prismatic [001]; commonly thin tabular (100); also tabular on (010) or dipyramidal (111) (in artificial crystals).

Type-locality form

1 inch (2.2 cm) square crystals in guano.

Comment

TMPM 32:187 (1983) structure

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
64.24%
15PPhosphorusPhosphorus130.97430.974
17.77%
12MgMagnesiumMagnesium124.30524.305
13.94%
1HHydrogenHydrogen71.0087.056
4.05%
Total174.328100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Newberyiet

In other languages

French
Hydrogénophosphate de magnésium trihydraté naturel · MgHPO4,3H2O (cristal) · Newbéryite
German
Newberyit
Italian
Newberyite
Chinese
镁磷石

Classification

Strunz
10th ed.

8.CE.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.10NewberyiteSpecies
Dana
8th ed.

39.01.06.01

  • 39Hydrated Acid Phosphates, Arsenates and VanadatesClass
  • 39.01A[HXO4]·xH2OType
  • 39.01.06— unnamed intermediate level —Group
  • 39.01.06.01NewberyiteSpecies
CIM

19.3.17

  • 19PhosphatesClass
  • 19.3Phosphates of Be and MgGroup
  • 19.3.17NewberyiteSpecies

Group, growth & confusion

Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1879vom Rath, G. (1879) Note sur deux nouveaux phosphates du guano. Bulletin de la Société Minéralogique de France: 2: 79-82. (paper includes note by Des Cloizeaux, M.)
  2. 1879vom Rath, G. (1879) Berichte Niederrheinische Gesellschaft für Natur und Heilkunde, Bonn: 36: 5.
  3. 1883Schmidt, A. (1883) Newberyit von Mejillones, Chile. Zeitschrift für Kristallographie-Crystalline Materials: 7(1-6): 26-35.
  4. 1887MacIvor R W E (1887) On Australian bat guano and some minerals occurring therein. The Chemical News 55, 215-216
  5. 1901Hoffmann, G.C. (1901) On some new mineral occurrences in Canada. American Journal of Science: Series 4: 11: 149-153.
