Struvite

(NH4)Mg(PO4) · 6H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Suv
Discovered
1846
Also known as

Where it forms, where it's found

Geological setting

Medieval sewers

Guano or dung deposits; peat beds; organically rich sediments.

Type locality
St Nikolai church
  1. Hamburg-Mitte
  2. Hamburg
  3. Germany

53.5475°, 9.9907°

29recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Dull · Earthy
Transparency
Transparent · Translucent
Colour
Colourless · white (dehydrated) · yellow or brownish · light grey · colourless in transmitted light.
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

On (001), good; on (100), poor.

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
1.711 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 37° · 2V calc = 40°
Refractive index
1.495 – 1.504
Surface relief
Low
Principal indices
nα 1.495 · nβ 1.496 · nγ 1.504
Dispersion
relatively weak
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#34
Cell parameters
a = 6.941(2) Å · b = 6.137(2) Å · c = 11.199(4) Å
Ratio a:b:c
1 : 0.884 : 1.613
Z
2
Morphology

Crystals equant; wedge-shaped (due to large and unequally developed (101) and (101)), coffin-shaped (when viewed along [100]); short prismatic [001], [010], or [100]; thick tabular (100). The distribution of the pyramidal or domical faces is often irregular. Crystals commonly distinct, to 2.5 cm (1 inch), with a distinct hemimorphic habit.

Twinning

On (001). The acute poles of [001] unite in the composition plane (001), with deep re-entrant angles.

Comment

Data from Whitaker and Jeffery (1970). Ferraris et al. (1986) give a = 6.955(1), b= 6.142(1), c = 11.218(2) Å.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
65.20%
15PPhosphorusPhosphorus130.97430.974
12.62%
12MgMagnesiumMagnesium124.30524.305
9.90%
1HHydrogenHydrogen161.00816.128
6.57%
7NNitrogenNitrogen114.00714.007
5.71%
Total245.404100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Guanit
  • Guanita
  • Guanite
  • Struveit
  • Struveita
  • Struveite

In other languages

French
NH4MgPO4·6H2O · struvite
German
Struvit
Spanish
Estruvita · Struvita
Italian
Struvite
Japanese
ストルバイト
Russian
Струвит

Classification

Strunz
10th ed.

8.CH.40

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CHWith large and medium-sized cations, RO4:H2O < 1:1Group
  • 8.CH.40StruviteSpecies
Dana
8th ed.

40.01.01.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.01AB(XO4)·xH2OType
  • 40.01.01Struvite GroupGroup
  • 40.01.01.01StruviteSpecies
CIM

19.3.23

  • 19PhosphatesClass
  • 19.3Phosphates of Be and MgGroup
  • 19.3.23StruviteSpecies

Group, growth & confusion

In the same group
2 members
Often grow together
4 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1845Ulex, G.L. (1845) Svenska Vetenskapsakademien, Stockholm, Handlingar [Ak. Stockholm, Öfv.]: 3: 32 (as Struveit).
  2. 1846Teschemacher (1846) Philosophical Magazine and Journal of Science: 28: 546 (as Guanite).
  3. 1846Ulex, G.L. (1846) Annalen der Physik, Halle, Leipzig: 58: 99 (as Struveit).
  4. 1847Hausmann, J.F.L. (1847) Handbuch der Mineralogie 3 volumes, Göttingen. Second edition: vol. 2, in two parts.
  5. 1847Ulex, G.L. (1847) Struvit. Öfversigt af Kongl. vetenskaps-akademiens förhandlingar, P. A. Norstedt & Söner. 32-33
