Pabstite

BaSnSi3O9
IMA status
  • Approved
IMA symbol
Pab
Discovered
1964
IMA approved
1964
Also known as
  • IMA1964-022
  • Pabstiet

Where it forms, where it's found

Type locality
Pacific Cement and Aggregate Company quarry
  1. Santa Cruz
  2. Santa Cruz County
  3. California
  4. USA

36.9826°, -122.0483°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Colourless · white

white with a pink tinge on a fresh surface

Density
4.03 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.674 – 1.685
Surface relief
High
Principal indices
nω 1.685 · nε 1.674
UV response
Bluish white in short-wave ultraviolet light.
Notes

RI is lower in less titanium rich material. see: Pautov, L. (2003): New Data on Minerals: 38: 15-19. anomalous interference colors in blue-violet or golden yellow

Michel-Lévy diagramhighlighted lineδ = 0.0110
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]110 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation110 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#111
Cell parameters
a = 6.7037(7) Å · c = 9.824(1) Å
Z
2
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
29.73%
56BaBariumBarium1137.327137.327
28.36%
50SnTinTin1118.710118.710
24.51%
14SiSiliconSilicon328.08584.255
17.40%
Total484.283100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1964-022
  • Pabstiet

In other languages

German
IMA 1964-022 · Pabstit
Italian
Pabstite

Classification

Strunz
10th ed.

9.CA.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CA[Si3O9]6- 3-membered single rings (dreier-Einfachringe), without insular complex anionsGroup
  • 9.CA.05PabstiteSpecies
Dana
8th ed.

59.01.01.03

  • 59Cyclosilicates Three-membered RingsClass
  • 59.01Three-Membered Rings, anhydrous, no other anionsType
  • 59.01.01Benitoite groupGroup
  • 59.01.01.03PabstiteSpecies
CIM

14.12.4

  • 14Silicates not Containing AluminumClass
  • 14.12Silicates of SnGroup
  • 14.12.4PabstiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1965Gross, E.G., Wainwright, J.E.N., Evans, B.W. (1965) Pabstite, the tin analogue of benitoite. American Mineralogist: 50: 1164-1169.
  2. 1972Choisnet, J., Deschanvres, A., Raveau, B. (1972) Sur de nouveaux germanates et silicates de type benitoite. Journal of Solid State Chemistry: 4: 209-218.
  3. 1984Alfors, John T., Pabst, Adolf (1984) Titanian taramellites in western North America. American Mineralogist, 69 (3-4) 358-373
  4. 1987Hawthorne, F.C. (1987) The crystal chemistry of the benitoite group minerals and structural relations in (Si3O9) ring structures. Neues Jahrbuch für Mineralogie, Monatshefte, 1987, 16-30.
  5. 2001(2001) Pabstite. Handbook of Mineralogy. Mineralogical Society of America
