Wadeite

K2ZrSi3O9
IMA status
  • Approved
  • Grandfathered
IMA symbol
Wad
Discovered
1938
Also known as
  • Wadeiet

Where it forms, where it's found

Geological setting

Leucite lamproites

Type locality
Walgidee Hills
  1. Noonkanbah Station
  2. Derby-West Kimberley Shire
  3. Western Australia
  4. Australia

-18.3095°, 124.8572°

31recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · light blue or pink
Cleavage
Poor/Indistinct
Fracture
Conchoidal
Density
3.10 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.624 – 1.673
Surface relief
Moderate
Principal indices
nω 1.624 – 1.627 · nε 1.655 – 1.673
Michel-Lévy diagramhighlighted lineδ = 0.0385
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]385 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation385 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#108
Cell parameters
a = 6.893(4) Å · c = 10.172(2) Å
Z
2
Morphology

As prisms, to 5 mm, and as hexagonal-shaped basal sections.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
36.21%
40ZrZirconiumZirconium191.22491.224
22.94%
14SiSiliconSilicon328.08584.255
21.19%
19KPotassiumPotassium239.09878.196
19.66%
Total397.666100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Fe
  • Mg
  • Sr
  • Na
  • H2O
  • P

Synonyms

  • Wadeiet

In other languages

German
Wadeit
Italian
Wadeite

Classification

Strunz
10th ed.

9.CA.10

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CA[Si3O9]6- 3-membered single rings (dreier-Einfachringe), without insular complex anionsGroup
  • 9.CA.10WadeiteSpecies
Dana
8th ed.

59.01.01.04

  • 59Cyclosilicates Three-membered RingsClass
  • 59.01Three-Membered Rings, anhydrous, no other anionsType
  • 59.01.01Benitoite groupGroup
  • 59.01.01.04WadeiteSpecies
CIM

14.10.13

  • 14Silicates not Containing AluminumClass
  • 14.10Silicates of Zr or HfGroup
  • 14.10.13WadeiteSpecies

Group, growth & confusion

In the same group
4 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1938Wade, A., Prider, R.T. (1938) The geology and petrology of the Kimberley district, Western Australia. Report of the British Association for the Advancement of Science, Cambridge: p. 419.
  2. 1939Prider, Rex T. (1939) Some minerals from the leucite-rich rocks of the West Kimberley area, Western Australia. Mineralogical Magazine and Journal of the Mineralogical Society, 25 (166) 373-387 doi:10.1180/minmag.1939.025.166.01 DOI: 10.1180/minmag.1939.025.166.01
  3. 1940(1940) New mineral names. American Mineralogist, 25 (3) 253-254
  4. 1955Mackenzie, R.C. (1955) Mineralogical Society (London). American Mineralogist: 40: 773-780.
  5. 1955Henshaw, D. E. (1955) The structure of wadeite. Mineralogical Magazine and Journal of the Mineralogical Society, 30 (228) 585-595 doi:10.1180/minmag.1955.030.228.04 DOI: 10.1180/minmag.1955.030.228.04
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Wadeite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/wadeite-4227},
  note      = {Accessed 2026-05-11}
}
