Pararobertsite

Ca2Mn3+3(PO4)3O2 · 3H2O
IMA status
  • Approved
IMA symbol
Prb
Discovered
1987
IMA approved
1987
Also known as
  • IMA1987-039
  • Pararobertsiet

Where it forms, where it's found

Geological setting

In secondary seams ina complex, zoned pegmatite.

Fracture fillings in late-stage mineralization in a phosphate-rich granite pegmatite.

Type locality
Tip Top Mine
  1. Fourmile
  2. Custer Mining District
  3. Custer County
  4. South Dakota
  5. USA

43.7156°, -103.6694°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Bronze · cinnamon brown · yellow · dark red

Usually dark red to cinnamon brown

Streak
Brown-red
Tenacity
brittle
Cleavage
Perfect

on (100)

Fracture
Irregular/Uneven
Density
3.22 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 84° · 2V calc = 85 – 88°
Refractive index
1.791 – 1.831
Surface relief
Very high
Principal indices
nα 1.791 · nβ 1.811 · nγ 1.831
Birefringence
0.040
Pleochroism
Weak

X = yellowish brown; Y = Z = reddish brown

Dispersion
extreme
Extinction
Z^c = 4°
UV response
Not fluorescent
Notes

Absorption: Z = Y > X

Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 8.825(3) Å · b = 13.258(4) Å · c = 11.087(3) Å
Cell angles
β = 101.19(4) °
Ratio a:b:c
1 : 1.502 : 1.256
Unit cell volume
1272.54 ų
Z
4
Morphology

Triangular to pseudo-rhombohedral plates, sometimes rhombic plates.

Type-locality form

Thin red transparent single plates, or clusters of plates, on whitlockite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1715.999271.983
44.16%
25MnManganeseManganese354.938164.814
26.76%
15PPhosphorusPhosphorus330.97492.922
15.09%
20CaCalciumCalcium240.07880.156
13.01%
1HHydrogenHydrogen61.0086.048
0.98%
Total615.923100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1987-039
  • Pararobertsiet

In other languages

German
IMA1987-039 · Pararobertsit
Italian
Pararobertsite
Portuguese
IMA1987-039 · Pararrobertsita

Classification

Strunz
10th ed.

8.DH.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DHWith large and medium-sized cations, (OH, etc.):RO4 < 1:1Group
  • 8.DH.30PararobertsiteSpecies
Dana
8th ed.

42.08.05.02

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.08(AB)5(XO4)3Zq·xH2OType
  • 42.08.05Kolfanite GroupGroup
  • 42.08.05.02PararobertsiteSpecies
CIM

19.12.7

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.7PararobertsiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1989Roberts, A. C., Sturman, B. D., Dunn, P. J., Roberts, W. L. (1989) Pararobertsite, Ca2Mn3+3(PO4)3O2·3H2O, a New Mineral Species from the Tip Top Pegmatite, Custer County, South Dakota, and its Relationship to Robertsite. The Canadian Mineralogist, 27 (3) 451-455
  2. 1990Jambor, John L.; Puziewicz, Jacek (1990) New Mineral Names. American Mineralogist, 75 (9-10). 1209-1216
  3. 2000Kampf, Anthony R. (2000) The crystal structure of pararobertsite and its relationship to mitridatite. American Mineralogist, 85 (9) 1302-1306 doi:10.2138/am-2000-8-924 DOI: 10.2138/am-2000-8-924
  4. 2005(2005) Pararobertsite. Handbook of Mineralogy. Mineralogical Society of America
