Rathite

Ag2Pb12-xTlx/2As18+x/2S40
IMA status
  • Approved
  • Grandfathered
IMA symbol
Rat
Also known as
  • Arsenomelane
  • Rathiet
  • Rathit I
  • +3 more

Where it forms, where it's found

Geological setting

Dolomite

Type locality
Lengenbach Quarry
  1. Fäld
  2. Binn
  3. Goms
  4. Valais
  5. Switzerland

46.3653°, 8.2205°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silver to lead-gray · tarnishes iridescent
Streak
Chocolate-brown
Cleavage
Perfect

(100) perfect.

Fracture
Conchoidal
Density
5.33 g/cm³

Optical

Pleochroism
Strong
Optical colour
White
Anisotropism
Strong; olive-green or yellow and bluish violet
Internal reflections
Deep red
Tropism
Anisotropic
Reflectance R%
(40.0,45.2) 400, (39.2,44.8) 420, (38.4,44.3) 440, (37.8,43.7) 460, (37.2,43.7) 480, (36.6,42.8) 500, (36.0,42.3) 520, (35.4,41.8) 540, (34.7,41.0) 560, (34.0,40.2) 580, (33.3,39.3) 600, (32.6,38.4) 620, (31.9,37.6) 640, (31.3,36.7) 660, (30.7,35.9) 680, (30.2,35.2) 700
Reflected-light panel
35.0 %anisotropic · dual curve
Specimen sRGB 205, 148, 87
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong; olive-green or yellow and bluish violet
Reflected colour
White
Internal reflections
Deep red

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 8.496(1) Å · b = 7.969(1) Å · c = 25.122(3) Å
Cell angles
β = 100.704(2) °
Ratio a:b:c
1 : 0.938 : 2.957
Morphology

Prismatic to short prismatic and striated [001].

Twinning

On (100) producing polysynthetic pseudo-orthorhombic crystals; also on {3¯01}. Exhibits polysynthetic twin lamellae of irregular thickness.

Parting
On (010).
Type-locality form

Striated crystals to a few millimeters in size.

Comment

Data from Berlepsch et al. (2002).

Crystal structure

Synonyms

  • Arsenomelane
  • Rathiet
  • Rathit I
  • Rathite-alpha
  • Wiltshireite
  • α-Rathite

In other languages

German
Rathit
Italian
rathite

Classification

Strunz
10th ed.

2.HC.05d

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HCWith only PbGroup
  • 2.HC.05dRathiteSpecies
Dana
8th ed.

03.07.12.01

  • 03SulfosaltsClass
  • 03.07ø = 2Type
  • 03.07.12— unnamed intermediate level —Group
  • 03.07.12.01RathiteSpecies
CIM

5.7.47

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.47RathiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1857von Waltershausen, W.S., Uhrlaub, E., Nason, H.B. (1857) Fortgesetzte Untersuchungen über die chemisch-mineralogische Beschaffenheit einiger Mineralkörper aus der Dolomitformation des Binnenthals im Wallis. Annalen der Physik, 176(4), 537-550 (540).
  2. 1896Baumhauer, H. (1896) XXVII. Ueber den Rathit, ein neues Mineral aus dem Binnenthaler Dolomit. Zeitschrift für Krystallographie und Mineralogie, 26 (1). 593-602 doi:10.1524/zkri.1896.26.1.593DOI: 10.1524/zkri.1896.26.1.593
  3. 1901Solly, R. H. (1901) Sulpharsenites of lead from the Binnenthal. Part II.—Rathite. Mineralogical Magazine and Journal of the Mineralogical Society, 13 (59). 77-85 doi:10.1180/minmag.1901.013.59.11 DOI: 10.1180/minmag.1901.013.59.11
  4. 1911Solly, R. H. (1911) On the relation between Rathite, Rathite α, and Wiltshireite. Mineralogical Magazine and Journal of the Mineralogical Society, 16 (74). 121-123 doi:10.1180/minmag.1911.016.74.08 DOI: 10.1180/minmag.1911.016.74.08
  5. 1912Lewis, W. J. (1912) On Rathite and its variety, Wiltshireite. Mineralogical Magazine and Journal of the Mineralogical Society, 16 (75). 197-206 doi:10.1180/minmag.1912.016.75.03 DOI: 10.1180/minmag.1912.016.75.03
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Rathite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/rathite-3370},
  note      = {Accessed 2026-05-11}
}
