Reichenbachite

Cu5(PO4)2(OH)4
IMA status
  • Approved
IMA symbol
Rbh
Discovered
1985
IMA approved
1985
Also known as
  • IMA1985-044
  • Reichenbachiet

Where it forms, where it's found

Geological setting

Silicified barite veins in diorites, gabbros, and ortho- and paragneisses.

Type locality
Point 8.0
  1. Borstein
  2. Reichenbach
  3. Lautertal (Odenwald)
  4. Bergstraße
  5. Darmstadt
  6. Hesse
  7. Germany

49.7127°, 8.6837°

24recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Dark green
Streak
Light green
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
4.35 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 76° · 2V calc = 76°
Refractive index
1.782 – 1.867
Surface relief
Very high
Principal indices
nα 1.782 · nβ 1.833 · nγ 1.867
Pleochroism
Weak

Very weak; X = bright emerald-green; Z = emerald-green.

Dispersion
Weak, r < v
Extinction
Y = b; Z ∧ a = 29(2)°.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0850
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]850 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation850 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 9.186(2) Å · b = 10.684(2) Å · c = 4.461(2) Å
Cell angles
β = 92.31(1) °
Ratio a:b:c
1 : 1.163 : 0.486
Z
2
Morphology

Lancet-shaped crystals.

Type-locality form

Crystals to 0.3 x 0.3 x 0.06 mm, lancet-shaped, and often intergrown with pseudomalachite.

Comment

SG P21/a

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper563.546317.730
55.19%
8OOxygenOxygen1215.999191.988
33.35%
15PPhosphorusPhosphorus230.97461.948
10.76%
1HHydrogenHydrogen41.0084.032
0.70%
Total575.698100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1985-044
  • Reichenbachiet

In other languages

French
Reichenbachite
German
Reichenbachit
Italian
Reichenbachite

Classification

Strunz
10th ed.

8.BD.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BDWith only medium-sized cations, (OH, etc.):RO4= 2:1Group
  • 8.BD.05ReichenbachiteSpecies
Dana
8th ed.

41.04.03.02

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.04(AB)5(XO4)2ZqType
  • 41.04.03— unnamed intermediate level —Group
  • 41.04.03.02ReichenbachiteSpecies
CIM

19.2.3

  • 19PhosphatesClass
  • 19.2Phosphates of CuGroup
  • 19.2.3ReichenbachiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1977Anderson, James B., Shoemaker, Gerald L., Kostiner, Edward, Ruszala, F. A. (1977) The crystal structure of synthetic Cu5(PO4)2(OH)4, a polymorph of pseudomalachite. American Mineralogist, 62 (1-2) 115-121
  2. 1987Sieber, Norbert H. W., Tillmanns, Ekkehart, Medenbach, Olaf (1987) Hentschelite, CuFe2(PO4)2(OH)2, a new member of the lazulite group, and reichenbachite, Cu5(PO4)2(OH)4, a polymorph of pseudomalachite, two new copper phosphate minerals from Reichenbach, Germany. American Mineralogist, 72 (3-4) 404-408
  3. 1991Hyršl, J. (1991) Three polymorphs of Cu5(PO4)2(OH)4 from Ľubietová, Czechoslovakia. Neues Jahrbuch für Mineralogie - Monatshefte, 1991 (6) 281-287
  4. 1994Braithwaite, R. S. W., Ryback, G. (1994) Reichenbachite from Cornwall and Portugal. Mineralogical Magazine, 58 (392) 449-454 doi:10.1180/minmag.1994.058.392.09 DOI: 10.1180/minmag.1994.058.392.09
  5. 2002Frost, Ray L., Williams, Peter A., Martens, Wayde, Kloprogge, J. Theo, Leverett, Peter (2002) Raman spectroscopy of the basic copper phosphate minerals cornetite, libethenite, pseudomalachite, reichenbachite and ludjibaite. Journal of Raman Spectroscopy, 33 (4). 260-263 doi:10.1002/jrs.850DOI: 10.1002/jrs.850
